Raven RP2B 3000mm Brush Strip 13mm Brush - Clear Anodised
The Raven RP2BX3000CA is a nylon brush strip seal supplied with an anodised aluminium carrier, designed to mount to the inside or outside of a door. It is commonly used at the bottom of single, double, or sliding doors and is often paired with Raven threshold plates to help manage door bottom clearances. The seal uses black fine, dense ultraviolet stabilised nylon filaments and can be fixed using the pre-applied self adhesive backing or screw fixed where required.
Key Features
- Brush strip seal with anodised aluminium carrier for surface mounting.
- Designed for door bottoms on single, double, or sliding doors.
- Black fine, dense ultraviolet stabilised nylon filaments.
- Clear anodised carrier finish.
- Fixing options include self adhesive backing or screw fixing.
- Commonly used in conjunction with Raven threshold plates.
- Energy reference to NCC Part 3.12.3.3 and J3.4.
Specifications
- Item Code: RP2BX3000CA
- Brand: Raven
- Door Seal Type: Brush seal
- Door Seal Set: Individual seal
- Carrier Material: Anodised aluminium
- Seal Material: Black fine, dense ultraviolet stabilised nylon filaments
- Fixing Method: Self adhesive or screw fixed
- Maximum Gap: Up to 13 mm (user determined)
- Overall Length: 3000 mm
- Finish: Clear Anodised
- Fire Rated: No
- Energy Reference: NCC Part 3.12.3.3 and J3.4
What's In The Box
- 1 × Brush strip seal with aluminium carrier - 3000 mm
Suitable Uses
- Bottom of single, double, or sliding doors where a surface mounted brush seal is required.
- Installations using threshold plates to manage floor clearance.
- Reducing draughts, dust, and general air movement through the door bottom gap.
Dimensions
Item Code Family
| Item Code | Product Name | Brush Size | Seal Type | Finish | Length |
|---|---|---|---|---|---|
| RP2BX3000BO | This model – Raven RP2B 3000mm Brush Only Seal | 13 mm | Brush Only (Concealed) | Black | 3000 mm |
| RP2BX3000CA | Raven RP2B 3000mm Brush Strip Seal with Aluminium Carrier | 13 mm | Brush Strip (Surface Mount) | Clear Anodised | 3000 mm |
Frequently Asked Questions
- Can this seal be screw fixed as well as self adhesive?
Yes. It can be applied using the self adhesive backing or screw fixed where required. - What surface conditions are required for the self adhesive backing?
The contact surface must be clean and smooth. Self adhesive seals may not adhere to oiled or alkyd finishes or to some easy clean wash and wear paint surfaces. - Is this normally used with a threshold plate?
It is commonly used in conjunction with Raven threshold plates to help manage clearances at the door bottom.
Additional Information
- Surface mounted brush seals are often chosen when a concealed door bottom groove is not practical or when retrofitting to existing doors.
- For best results with adhesive fixing, installers typically degrease the mounting face and avoid newly painted surfaces until fully cured.
- When paired with a threshold plate, the brush is less likely to snag on uneven flooring and can provide a more consistent seal line.
