Raven RP26 Door Bottom Sweep Seal - Clear Anodised

Raven RP26 Door Bottom Sweep Seal - Clear Anodised

The Raven RP26 is a heavy duty aluminium door bottom sweep seal designed for outward opening doors. Slotted fixing holes allow adjustment and are concealed behind a push-in cover strip. The RP26 is commonly used in conjunction with Raven threshold plates.

Key Features

• Heavy duty sweep seal for outward opening doors
• Concealed screw fixing with push-in cover strip
• Pre-slotted fixing holes for on-site adjustment
• Suitable for single and double butt hinged doors
• Can be used on tilt-up doors or as an astragal seal
• Compatible with Raven threshold plates

Compatibility

• Bottom of outward opening butt hinged doors
• Single and double door applications
• Tilt-up doors
• Used with Raven RP29 threshold plates
• Suitable for gap ranges between 5 mm and 20 mm

Full Specifications

Whats in the Box

• 1 x Raven RP26 Door Bottom Sweep Seal
• Zinc plated cross recess head self tapping screws
• Push-in cover strip

Frequently Asked Questions

• Is this seal fire rated?
  Yes. Tested to AS1530.4 and compliant with AS/NZS 1905.1 when installed in approved door assemblies.
• What gap can it seal?
  Designed to seal gaps between 5 mm and 20 mm depending on installation height.
• Does it include fixings?
  Yes. Zinc plated self tapping screws and a cover strip are supplied.

Additional Information

• Commonly specified in Australian commercial buildings and fire door upgrades.
• Often paired with Raven RP29 threshold plates for improved sealing performance.
• Pre-slotted holes allow adjustment during installation to fine tune contact pressure.
