Protector 485 Series Mortice Sash Lock Pitch 85mm

Protector 485 Series Mortice Sash Lock Pitch 85mm

Heavy duty euro style mortice lock designed for narrow stile applications, featuring an 85 mm pitch and fixed cam euro cylinder operation (cylinder not included).

Key Features

• Euro cylinder operated mortice lock (cylinder not included).
• Pitch 85 mm with 8 mm spindle hub.
• Easily reversible latch without opening the case.
• Single throw 15 mm deadbolt.
• Key retracts latch.
• Supplied with euro cylinder retaining screw.
• Supplied with black plastic escutcheons, strike plate and fixing screws.
• Supplied boxed.

Compatibility

• Suitable for doors prepared for 85 mm pitch mortice locksets.
• Compatible with fixed cam euro profile cylinders (sold separately).
• Designed for narrow stile and similar mortice lock applications.

Full Specifications

Available Finish Options

Satin Brass

Satin Stainless Steel

Whats In The Box

• Protector 485 Series mortice sash lock body.
• Strike plate.
• Black plastic escutcheons.
• Euro cylinder retaining screw.
• Fixing screws.

Dimension

Frequently Asked Questions

• Is the euro cylinder included?
  No. This lock is supplied less cylinder. A fixed cam euro profile cylinder is required and sold separately.
• What backset options are available?
  This lock is available in 20 mm, 25 mm, 30 mm, 35 mm and 40 mm backsets depending on the selected item code.
• Is the latch reversible?
  Yes. The latch is easily reversible without opening the case.

Additional Information

• Supplied with black plastic escutcheons, strike plate and fixing screws for standard installation.
• Choose the correct backset to suit the door stile and existing mortice preparation.
• Professional installation recommended to ensure correct latch and strike alignment.
