Permaconn Dual SIM 4G and IP Communicator with Router and Wi-Fi Hotspot
The Permaconn PM54 is a dual SIM 4G and IP alarm communicator that combines alarm reporting, routing, and Wi-Fi hotspot functionality in a single device. It is designed to provide secure, high-availability communications for alarm panels, access control systems, and other network-connected security equipment.
Key Features
- Alarm communicator, router, and Wi-Fi hotspot operate simultaneously.
- Dual SIM 4G cellular connectivity with automatic failover and failback.
- Primary IP communication with cellular fallback when Ethernet is unavailable.
- Supports remote alarm panel upload and download.
- Plug-and-play installation with remote configuration via Atlas.
- Designed to be powered directly from an alarm panel power supply.
Specifications
- Item Code: PM54
- Product Type: Dual SIM 4G and IP alarm communicator with router and Wi-Fi hotspot
- Cellular Technology: 4G LTE-FDD and 3G HSDPA+
- 4G Bands: B1 (2100), B3 (1800), B5 (850), B8 (900), B28 (700)
- 3G Bands: B1 (2100), B5 (850), B8 (900)
- Wi-Fi: IEEE 802.11 b/g/n, 2.4 GHz
- Wi-Fi 5 GHz: No
- Ethernet: 3 × RJ-45 ports, 10/100Base-T, Auto MDI/MDIX
- Serial Interface: High speed RS-232
- Routing Functions: IP pass-through, NAT, NAPT, port forwarding, Ethernet bridging, DHCP, DNS client and server
- Failover: Automatic failover and failback to second SIM, Wi-Fi, or Ethernet (configuration dependent)
- Management: Remote configuration via Atlas web portal
- Data Modem: 2400 baud modem for alarm panel remote upload and download
- Auxiliary Inputs: 3 × 24-hour inputs, EOL 3.3 kilo-ohm
- Auxiliary Outputs: 3 × open collector outputs, 50 milliamps maximum
- Power Supply: 10 volts DC to 15 volts DC
- Current Consumption: Idle 0.12 amps at 13.8 volts DC
- Dimensions: 110 mm (height) × 25 mm (depth) × 80 mm (width)
- Weight: 180 grams
What's In The Box
- Permaconn PM54 communicator unit
Suitable Uses
- Monitored alarm systems requiring dual-path communications.
- Sites needing IP connectivity with 4G cellular backup.
- Installations requiring temporary or permanent Wi-Fi hotspot capability.
Permaconn Communicator - Item Code Family
Download PDF Resources
|
AUST PM54 Brochure |
Frequently Asked Questions
- What happens if the Ethernet connection fails?
The communicator automatically fails over to cellular communication using the installed SIMs.
- Can this be powered directly from an alarm panel?
Yes. It operates within the specified 10 volts DC to 15 volts DC input range.
- Does this support Wi-Fi on 5 GHz?
No. Wi-Fi support is listed as 2.4 GHz only.
Additional Information
- The PM54 combines alarm reporting and site networking where a single device is preferred.
- Failover can move between Ethernet, Wi-Fi, and cellular paths depending on site configuration.
- Atlas is used for remote configuration and diagnostics.
