Nidac Prove Series B Dual Frequency Wallplate Keypad Reader - Dark Grey
The Nidac Prove Series B keypad and reader is weather resistant and tested to IP67, making it suitable for indoor or outdoor use where a rugged keypad with integrated RFID is required.
Key Features
- Weather resistant keypad and reader tested to IP67.
- Illuminated membrane keypad with locator pip to aid the visually impaired.
- Configurable tricolour LED light pipes for visual feedback.
- Tough polycarbonate shell and chassis for demanding outdoor environments.
- Dual frequency reader supporting 125 kHz and 13.56 MHz (UID and CSN only).
- Advanced accelerometer anti tamper protection.
- Compatible with Presco, Prescient, and other Wiegand based controllers.
- Includes slide and lock mounting plate.
- Designed and manufactured in Australia with factory testing and 5 year warranty.
Specifications
- Item Code: NPEBDF43C
- Brand: Nidac
- Product Type: Wallplate keypad reader
- Finish: Dark Grey
- IP Rating: IP67
- Keypad Layout: 3x4
- Wiegand Output: Yes
- Working Voltage: 9 Vdc to 28 Vdc
- Country of Manufacture: Australia
- Reader Frequency: 125 kHz and 13.56 MHz
- Supported Card Formats: EM Prox, HID Prox, Presco
- Read Range: Prove fob 4 cm, Prove card 9 cm
- Code Combinations: 11 million
What's In The Box
- 1 x Nidac Prove Series B dual frequency wallplate keypad reader
- Slide and lock mounting plate
Suitable Uses
- Indoor or outdoor access control entry points where IP67 weather resistance is required.
- Sites needing keypad plus RFID credential entry (dual frequency).
- Installations using Wiegand based controllers such as Presco, Prescient, or compatible third party controllers.
Dimensions
| Measurement | Size (mm) |
|---|---|
| Width | 80 |
| Height | 130 |
| Depth | 25 |
PDF Resources
Frequently Asked Questions
- Is this keypad suitable for outdoor installation?
Yes. It is tested to IP67 and is suitable for indoor or outdoor use. - Does it work with Wiegand controllers?
Yes. It provides Wiegand output and is stated as compatible with Presco, Prescient, and other Wiegand based controllers. - What frequencies does the reader support?
It supports 125 kHz and 13.56 MHz (UID and CSN only).
Additional Information
- For best performance on Wiegand installations, follow controller wiring and format configuration requirements during commissioning.
- In exposed outdoor sites, installers commonly prioritise correct sealing of cable entries and appropriate mounting surfaces to maintain long term weather resistance.
- Credential format support can vary by system. Confirm the controller supports the intended card or fob format before deployment.
