Neptune NEKPWST2W Standalone / Wiegand Capacitive Touch Keypad with HID / EM / Mifare Reader – IP65
The Neptune NEKPWST2W is a vandal-resistant capacitive touch keypad with integrated multi-format proximity reader. It supports EM 125 kilohertz, HID 125 kilohertz and Mifare 13.56 megahertz credentials and can operate as either a standalone single door controller or as a Wiegand reader connected to an external access control panel.
Designed for Australian commercial and residential installations, the IP65-rated zinc alloy housing and reinforced glass touch surface make it suitable for exposed locations.
Key Features
- Standalone single door controller or Wiegand reader mode.
- Supports EM 125 kilohertz, HID 125 kilohertz and Mifare 13.56 megahertz credentials.
- Capacitive 3 x 4 touch keypad with backlight control modes.
- IP65 rated for outdoor installation.
- Zinc alloy vandal-resistant housing with reinforced glass panel.
- Up to 2000 user capacity.
- Wiegand 26 to 37 bit output.
- Anti-tamper alarm output.
Specifications
- Item Code: NEKPWST2W
- Operating Voltage: 12 to 24 Volt Direct Current
- Idle Current: 50 milliampere or less
- User Capacity: 2000 users
- Card Frequency: 125 kilohertz EM / HID; 13.56 megahertz Mifare ISO14443A
- Reading Range: Up to 5 centimetre at 125 kilohertz; up to 2 centimetre at 13.56 megahertz
- Wiegand Output: 26 to 37 bit
- Keypad Output: 4 bit, 8 bit or virtual card
- Ingress Protection: IP65
- Operating Temperature: -40 to 60 degrees Celsius
- Operating Humidity: 0 to 95 percent non-condensing
- Dimensions: 145 millimetre height x 83 millimetre width x 26 millimetre depth
- Anti-Tamper: Yes
What's In The Box
- Neptune NEKPWST2W keypad unit
- Mounting plate
- Fixing screws and wall plugs
- Installation manual
Suitable Uses
- Standalone access control for single door installations.
- Integration with universal access control panels via Wiegand.
- Commercial offices, warehouses and strata common areas.
- External gate or entry points requiring IP65 protection.
Dimensions
Neptune Capacitive Keypad Series – Item Code Family
Download PDF Resources
Frequently Asked Questions
- Can this keypad operate without an external controller?
Yes. In standalone mode it can directly control a single electric strike or magnetic lock using its onboard relay. - Can it be used with an existing access control system?
Yes. It supports Wiegand 26 to 37 bit output for connection to compatible access control panels. - Is it suitable for outdoor installation?
Yes. The IP65 rating and sealed housing allow installation in exposed external locations.
Additional Information
- Commonly specified in Australian commercial sites where multi-format card support is required without changing legacy credentials.
- When used in standalone mode, ensure the power supply is correctly rated for the connected locking device.
- Reader mode disables internal relay control and requires a compatible access control panel.
