Neptune Resettable Call Point with LED Light and Buzzer
The Neptune resettable emergency call point is a triple pole manual activation unit designed for alarm triggering, door release and emergency signalling systems. The device includes LED state illumination, an adjustable internal buzzer and three independent relay outputs allowing multiple actions to be triggered simultaneously when activated.
Unlike traditional break glass units, this call point features a resettable activation window. After activation the unit can be reset using the supplied key, eliminating the need to replace broken glass and reducing maintenance costs in high use environments.
Key Features
- Resettable manual call point design with no breakable glass.
- Dual colour LED indicator shows system state.
- Internal adjustable buzzer for audible alert.
- Triple pole outputs including Normally Open, Normally Closed and Common relay contacts.
- Configurable LED and buzzer operation modes.
- Manual reset using supplied key.
- Suitable for door release, alarm triggering and safety signalling systems.
Compatibility
- Commonly used with fire alarm control panels.
- Suitable for emergency door release systems.
- Can trigger electromagnetic door locks and hold open devices.
- Compatible with security alarm or access control trigger circuits operating between 12VDC and 24VDC.
Full Specifications
Available Finish Colour
Whats in the Box
- Neptune resettable emergency call point unit.
- Reset key.
- Mounting screws and fixings.
Dimension
Item Code Family
| Series | Item Code | Colour | Blue Backlight | Notes |
|---|---|---|---|---|
| Neptune Resettable Call Point DPdt with Protective Cover - Buzzer - Key Reset At The Front | NECP32GBZLB | Green | Yes | Protective cover, buzzer, front key reset |
| Neptune Resettable Call Point DPdt with Protective Cover - Buzzer - Key Reset At The Front | NECP32G | Green | No | Protective cover, buzzer, front key reset |
| Neptune Resettable Call Point DPdt with Protective Cover - Buzzer - Key Reset At The Front | NECP32W | White | No | Protective cover, buzzer, front key reset |
| Neptune Resettable Call Point with LED Light and Buzzer | NECPLBGN | Green | Not specified | LED light and buzzer |
| Neptune Resettable Call Point with LED Light and Buzzer | NECPLBWH | White | Not specified | LED light and buzzer |
Frequently Asked Questions (FAQ)
- Does this unit require replacement glass after activation?
No. The unit uses a resettable activation window which can be reset using the supplied key. - Can this call point trigger more than one device?
Yes. The triple pole output allows multiple actions such as alarm activation, door release and magnetic hold open release. - Is the buzzer adjustable?
Yes. The internal buzzer can be configured for silent, intermittent or continuous operation and the volume can be adjusted internally.
Additional Information
- Resettable emergency call points are commonly installed in access control systems where an emergency door release is required.
- The triple pole relay design allows one activation to perform several functions such as triggering an alarm and unlocking secure doors.
- Adjustable LED and buzzer behaviour allows installers to configure the device for different system requirements.
- Resettable activation reduces maintenance costs compared with traditional break glass units.
Download PDF Resources
|
Neptune Resettable Call Point User Manual |
Neptune Warranty
Neptune Security Products are covered by a 3 year manufacturer warranty against defects in materials and workmanship from the date of purchase. For full warranty terms and conditions please refer to the official Neptune document here.
