Neptune Illuminated Press To Exit Button with Architrave Plate
The Neptune ACWES1611 is a stainless steel illuminated press to exit button mounted on a standard architrave size faceplate. It features a green LED indicator and isolated NO and NC contacts, making it suitable for a wide range of access control exit applications.
Key Features
- Illuminated press to exit button with green LED.
- Stainless steel architrave size faceplate.
- Isolated normally open and normally closed contacts.
- 12 to 24 VDC operating range.
- Flying lead terminals for easy connection.
- Compact design for narrow mounting locations.
Specifications
- Item Code: ACWES1611
- Finish: Stainless Steel
- Operating Voltage: 12 to 24 VDC
- Maximum Current: 2 A
- Minimum Current: 5 mA
- Contacts: 1 x NO and 1 x NC (isolated)
- LED Indicator: Yes, green
- Electrical Life: 50,000 cycles
- Mechanical Life: 1,000,000 cycles
- Terminals: Flying leads
- Operation: Touch
- Text on Plate: PRESS TO EXIT
What's In The Box
- 1 x illuminated press to exit button with architrave faceplate
Suitable Uses
- Access control exit release points.
- Commercial or office door installations.
- Narrow architrave or limited mounting spaces.
Dimensions
| Height | 75 mm |
| Width | 30 mm |
| Depth | 32 mm |
Frequently Asked Questions
- What voltage does this button operate on?
It operates on 12 to 24 VDC systems. - Does it include both NO and NC contacts?
Yes, it has isolated normally open and normally closed contacts. - Where is this style typically installed?
It is commonly used on architraves or narrow mounting areas next to doors.
Additional Information
- Green LED improves visibility and indicates the exit point.
- Compact architrave plate suits narrow mounting areas.
- Designed for integration with electric strikes and magnetic locks.
