Neptune Maglock Single Door
The Neptune Single Door Maglock is a monitored electromagnetic locking solution designed for secure access control installations. It delivers strong holding force while allowing system monitoring through built in sensors and LED indicators.
This maglock supports dual voltage operation and includes a door status sensor with adjustable delay settings, making it suitable for commercial access control environments.
Key Features
- Monitored electromagnetic lock
- Single door installation
- Dual voltage 12VDC / 24VDC
- Door status monitoring sensor
- LED lock status indicator
- Adjustable delay 0, 3, 6 or 9 seconds
- Holding force up to 500kg
- Compatible with L and L&Z brackets
Compatibility
- Access control systems
- Commercial security doors
- Office entry doors
- Maglock mounting bracket installations
Full Specifications
| Brand | Neptune |
| Door Type | Single Door |
| Holding Force | 280kg / 500kg |
| Working Voltage | 12VDC – 24VDC |
| Current Draw | 12VDC @ 480mA / 24VDC @ 240mA |
| Door Status Sensor | Yes |
| LED Indicator | Yes |
| Time Delay | 0 / 3 / 6 / 9 seconds |
| Finish | Silver / Black |
What's in the Box
- Neptune magnetic lock
- Armature plate
- Mounting hardware
Dimensions
| Magnet Size | 250 x 47 x 26 mm |
| Armature Plate | 180 x 36 x 11 mm |
| Weight | 2 kg |
Frequently Asked Questions (FAQ)
- What holding force does the maglock provide?
The maglock provides either 280kg or 500kg holding force depending on the model.
- Is the maglock monitored?
Yes. It includes monitoring with a door status sensor and LED indicator.
- Can this lock be installed outdoors?
This model is designed for indoor use.
Additional Information
- Suitable for access control security installations
- Compatible with Neptune bracket accessories
- Reliable electromagnetic locking solution
Warranty
Manufacturer warranty applies to defects in materials and workmanship.
