Neptune monitored double door mag lock
Suitable for Indoor use only.
- Double door monitored magnetic lock.
- Dual voltage 12vdc @ 480mA, 24vdc @ 240mA per magnet.
- Monitored, door status sensor.
- LED indicator.
- The overload current of relay contact is 1amp. Overload is strictly prohibited for voltage of 24V-DC.
- Built-in time delay 0, 3, 6 or 9 seconds.
- Holding force up to 500kgs per magnet.
- Matt black aluminium housing.
- Zinc plated electromagnetic body.
- Weight 9kg.
- L and Z mounting brackets are also available.
Technical Specifications
| Brand | NEPTUNE |
| Finish | Matt Black or Satin Anodised |
| Working Voltage | 12 Vdc to 24 Vdc |
| Door Status Sensor | Yes |
| Holding Force In Kg | 240 - 500 |
| LED Indicator | Yes |
| Time Delay | Yes |
| Single Or Double Door Maglock? | Double |
| Monitoring | Monitored |
