Neptune BNC RG59/U Crimp Connector – 75 Ohm
The Neptune TVCN01 is a BNC crimp connector designed for termination of RG59/U coaxial cable. It is commonly used in analogue video and CCTV installations where a 75 ohm impedance connection is required. Crimp termination provides a secure mechanical connection suitable for professional cable assembly.
Key Features
- BNC male crimp connector for coaxial cable termination.
- Designed specifically to suit RG59/U coaxial cable.
- 75 ohm impedance for video signal transmission.
- Crimp-style termination for secure and consistent connections.
- Commonly used in CCTV and analogue video systems.
Specifications
- Item Code: TVCN01
- Connector Type: BNC
- Cable Type: RG59/U coaxial cable
- Impedance: 75 ohm
- Termination Method: Crimp
- Finish: Silver
What's In The Box
- 1 × Neptune BNC RG59/U crimp connector
Suitable Uses
- CCTV camera cabling using RG59/U coaxial cable.
- Analogue video signal connections.
- Security and surveillance installations.
- Professional cable fabrication and repairs.
Frequently Asked Questions
- Is this connector suitable for RG6 cable?
No. This connector is designed specifically for RG59/U coaxial cable. RG6 requires a different connector size. - Does this connector require a special tool?
Yes. A compatible BNC crimping tool is required to correctly terminate the connector onto the cable. - Is this suitable for digital HD video?
It is commonly used for analogue CCTV systems. Digital and HD systems may require different cabling and connectors depending on the technology.
Additional Information
- Correct cable stripping length is critical to ensure proper crimp and signal integrity.
- Common installation issues include under-crimping or over-crimping, which can cause intermittent video loss.
- This connector is widely specified in Australian CCTV installations using RG59 siamese cable.
