Neptune 6 Channel - 4 Button RF Remote with Slide Cover - Default Programming
Neptune 6 Channel - 4 Button RF Remote with Slide Cover - Default Programming

Neptune 6 Channel - 4 Button RF Remote with Slide Cover - Default Programming

Neptune

$48.40
(No reviews yet) Write a Review
SKU:
STK NEF4S
UPC:
9329673225604
Availability:
Usually same day dispatch (if ordered before 11am)
Adding to cart… The item has been added
Neptune logo

Neptune 6 Channel 4 Button RF Remote with Slide Cover - Default Programming

Key features icon Key Features

  • 6 channel RF remote with four button operation.
  • Sliding cover reduces accidental button activation.
  • Additional channels activated by combined button presses.
  • 26 bit Wiegand standard encoding.
  • Keeloq code hopping transmission security.
  • Up to 100 metre range in open air conditions.

Specifications icon Specifications

  • Item Code: NEF4S
  • Brand: Neptune
  • Product Type: RF remote transmitter
  • Channels: 6 channels
  • Buttons: 4 button operation
  • Combined Functions: Buttons 1 and 2 activate channel 5; buttons 3 and 4 activate channel 6
  • Encoding: 26 bit Wiegand standard
  • Operating Frequency: 433.92 MHz
  • Modulation: Amplitude Shift Keying (ASK)
  • Transmission Security: Keeloq code hopping
  • Battery: 1 x CR2032 lithium cell
  • RF Range (open air): Up to 100 metres
  • RF Range (urban): Approximately 30 metres
  • Operating Temperature: -10 to 50 degrees Celsius
  • Approvals: C-Tick, CE
  • Finish: Black

Contents icon What's In The Box

  • 1 x Neptune NEF4S RF remote transmitter with slide cover
  • 1 x CR2032 battery (pre-installed)

Suitable uses icon Suitable Uses

  • Car park and gate access control.
  • Alarm panel arming and disarming.
  • Standalone relay receiver systems.
  • Wiegand-based access control integrations.

Accessories icon Accessories & Spares

Item Code Description Notes
NEREC6M Standalone relay receiver Compatible receiver, sold separately
NEREC6IPM Standalone IP relay receiver Compatible receiver, sold separately
NEREC6MW Wiegand receiver Compatible receiver, sold separately
NEREC6IPMW IP Wiegand receiver Compatible receiver, sold separately

FAQ icon Frequently Asked Questions

  • What is the purpose of the slide cover?
    The slide cover helps prevent accidental button presses during transport or storage.
  • Can this remote be reprogrammed with a custom site code?
    No. This model is supplied with a fixed default site code and user number and is not customisable.
  • What is the typical operating range?
    Up to 100 metres in open air conditions, or around 30 metres in typical urban environments.

Additional information icon Additional Information

  • Sliding cover design is commonly specified where accidental activation could cause nuisance gate or door operation.
  • Default programming allows fast installation without site code configuration.
  • Installers should confirm receiver compatibility, frequency, and channel requirements before installation.

.

!
