Neptune 3 Channel 2 Button RF Remote - Default Programming
Key Features
- 3 channel RF remote with two buttons and multi-function operation.
- 26 bit Wiegand standard encoding.
- Keeloq code hopping transmission security.
- Up to 100 metre range in open air conditions.
- Pre-programmed with default site code and user number.
Specifications
- Item Code: NEF2B
- Brand: Neptune
- Product Type: RF remote transmitter
- Channels: 3 channels
- Buttons: 2 button operation (combined press activates third channel)
- Encoding: 26 bit Wiegand standard
- Operating Frequency: 433.92 MHz
- Modulation: Amplitude Shift Keying (ASK)
- Transmission Security: Keeloq code hopping
- Battery: 1 x CR2032 lithium cell
- RF Range (open air): Up to 100 metres
- RF Range (urban): Approximately 30 metres
- Operating Temperature: -10 to 50 degrees Celsius
- Approvals: C-Tick, CE
- Finish: Black
What's In The Box
- 1 x Neptune NEF2B RF remote transmitter
- 1 x CR2032 battery (pre-installed)
Suitable Uses
- Car park and gate access control.
- Alarm panel arming and disarming.
- Standalone relay receiver systems.
- Wiegand-based access control integrations.
Accessories & Spares
Frequently Asked Questions
- Can this remote be reprogrammed with a custom site code?
No. This model is supplied with a fixed default site code and user number and is not customisable. - What receivers does this remote work with?
It is designed to work with compatible Neptune standalone relay or Wiegand receivers. - What is the typical operating range?
Up to 100 metres in open air conditions, or around 30 metres in typical urban environments.
Additional Information
- Commonly used for car park access, gate automation, and alarm control systems.
- Default programming makes it suitable for quick deployments where custom site coding is not required.
- Installers should confirm receiver compatibility and frequency before deployment.
