Neptune 2.1mm DC Screw Connect Power Socket
Key Features
- 2.1 mm DC socket with screw-down terminal connection.
- Direct connection to bare figure-8 power cable.
- No soldering or heat shrink required.
- Quick and simple field termination.
Specifications
- Item Code: TVCN21S
- Brand: Neptune
- Product Type: DC screw connect power socket
- Connector Size: 2.1 mm x 5.5 mm DC
- Connection Method: Screw-down terminals
- Cable Type: Bare figure-8 power cable
- Finish: Black
What's In The Box
- 1 x Neptune 2.1 mm DC screw connect power socket
Suitable Uses
- Low-voltage DC power connections for security and electronic equipment.
- Field termination of power leads where soldering is not practical.
- CCTV cameras, access control devices, and alarm accessories using 2.1 mm DC plugs.
Frequently Asked Questions
- Does this require soldering to connect the wires?
No. The socket uses screw-down terminals so bare wires can be connected directly. - What size DC plug suits this socket?
It is designed for standard 2.1 mm x 5.5 mm DC barrel plugs commonly used in security equipment. - Is this suitable for outdoor use?
This is a standard indoor connector. Outdoor installations should be housed in a suitable weather-protected enclosure.
Additional Information
- Commonly used in CCTV and access control installations for quick DC power terminations.
- Helps reduce installation time compared with soldered DC connectors.
- Ensure correct polarity when terminating to avoid equipment damage.
