LOX ES20 High Security Electric Strike 10–30VDC 4 Hour Fire Rated
Key Features
- LOX LES20 high security electric strike designed for access control systems.
- Multi voltage operation from 10VDC to 30VDC.
- Field selectable fail safe or fail secure locking.
- Stainless steel construction for durability.
- Holding strength exceeding 1490 kg.
- 10 mm strike lip supplied as standard to reduce risk of clothing damage.
- 5 mm lip extension included.
- Solenoid suitable for continuous duty operation.
- Fire rated installation up to 4 hours.
- Includes tab mounting kit and adhesive installation template.
- Pre drilled for optional extension lips.
Compatibility
- Designed for hinged doors in access control systems.
- Suitable for aluminium, timber and steel door frames.
- Compatible with a wide range of mortice locks and latches.
- Designed for 18 mm latch with 3 mm door gap.
- Suitable for commercial and industrial security installations.
Full Specifications
Fire Rated
- Successfully fire rated up to 4 hours on fire door assemblies.
- Tested in accordance with AS/NZS 1905 Part 1-1997 and BS 476 Part 22-1987.
Available Finish Color
Black
Silver
Whats In The Box
- LOX ES20 electric strike.
- 5 mm strike lip extension.
- Tab mounting kit.
- Self adhesive installation template.
- Mounting hardware.
Dimension
Item Code Family
| Item Code | Product | Model |
|---|---|---|
| LOX ES10 Electric Strike 12 or 24VDC 4 Hour Fire Rated IP56 - Black/Silver | ||
| LES10 | LOX ES10 Electric Strike | Non-Monitored |
| LES10M | LOX ES10 Electric Strike | Monitored |
| LOX ES20 High Security Electric Strike 10–30VDC 4 Hour Fire Rated - Black/Silver | ||
| LES20 | LOX ES20 High Security Electric Strike | Non-Monitored |
Download PDF Resources
|
LOX ES20 Electric Strike Datasheet |
|
LOX ES20 Installation Manual |
|
Fail Safe / Fail Secure Changeover Guide |
Frequently Asked Questions (FAQ)
- Can the ES20 be installed on fire doors?
Yes. The strike is fire rated up to 4 hours when installed on approved fire door assemblies. - Is the locking mode configurable?
Yes. Fail safe or fail secure mode can be selected during installation. - What is the holding strength?
The ES20 electric strike provides holding strength of over 1490 kg.
Additional Information
- Designed for high security commercial access control systems.
- Stainless steel construction improves durability and corrosion resistance.
- Suitable for heavy duty commercial doors and high traffic entry points.
