LOX ES15 Rim Mount Electric Strike 12–24V DC Non-Monitored IP56 – Black / Silver
The LOX ES15 is a surface mounted electric strike suitable for use with rim or surface type dead latches. It is easily installed and works with access control systems, with field selectable fail secure or fail safe operation.
Key Features
- Surface mounted electric strike for rim and surface type dead latches.
- Dual voltage: 12V DC at 200mA, 24V DC at 100mA.
- Continuously rated coil.
- Power to lock or power to open field changeable.
- Weather resistant IP56 (non-monitored model).
- Holding strength over 1252 kg.
- 2 hour fire rating.
- Monitored version available (LES15M).
Specifications
| Specification | Details |
|---|---|
| Item Code | LES15 |
| Brand | LOX |
| Working Voltage | 12–24V DC |
| Current | 200mA @ 12V / 100mA @ 24V |
| Holding Strength | 1252 kg |
| IP Rating | IP56 |
| Fire Rated | No |
| Locking Mode | Fail Secure / Fail Safe (Field Selectable) |
| Monitoring | Non-Monitored |
| Finish | Black / Silver |
What's In The Box
- LOX ES15 rim mount electric strike
Suitable Uses
- Rim or surface dead latch installations.
- Access control upgrades where a surface mounted electric strike is required.
- External applications requiring IP56 (non-monitored model).
Dimensions
| Component | Measurement (mm) |
|---|---|
| Strike Body Length | 200 |
| Strike Body Height | 38 |
| Strike Depth | 16.2 |
Frequently Asked Questions
- What locks does the ES15 suit?
It is suitable for rim or surface type dead latches. - Can the locking mode be changed?
Yes. Power to lock or power to open is field changeable (fail secure or fail safe). - Is there a monitored version?
Yes. A monitored version is available as model LES15M.
Additional Information
- Weather resistant rating applies to the non-monitored model.
- 5 year warranty.
Technical Drawing
.
