Dormakaba ED22 Double Pack Exit Only Panic Device – Silver
Key Features
- Double pack panic exit device for emergency egress on double doors.
- Exit only configuration for secure internal egress.
- Horizontal touch bar design for single action exit.
- Deadlatching mechanism for improved security.
- Standard length 1085 mm, field sizable down to 645 mm.
- Field selectable handing for installation flexibility.
- Finished in silver.
Specifications
- Item Code: BOED22DPEOSIL
- Brand: Dormakaba
- Series: ED22DP
- Configuration: Exit only double pack
- Finish: Silver
- Standard Length: 1085 mm
- Minimum Cut Length: 645 mm
- Door Thickness: 35 to 50 mm
- Handing: Field selectable
- Dogging: Hex key dogging
- Fire Rated: No
What’s In The Box
- 2 × Dormakaba ED22 exit devices
- Mounting hardware
- Installation components
Suitable Uses
- Commercial double door emergency exits.
- Office buildings, schools, and public facilities.
- Metal or timber double door applications.
- Areas requiring simple, reliable emergency egress.
Dimensions
Frequently Asked Questions
- Is this device suitable for fire rated doors?
No. This exit only model is not fire rated. A fire rated version should be selected where required. - Can the device be cut down to suit smaller doors?
Yes. The standard 1085 mm length can be field sized down to a minimum of 645 mm. - Does this device include external access trim?
No. This is an exit only configuration intended for internal egress only.
Additional Information
- Double pack configuration provides coordinated egress across both leaves of a double door set.
- Deadlatching function helps prevent forced retraction of the latch from the outside.
- Field sizing allows installers to adapt the device to various door widths without special ordering.
