Jack Fuse Electronic Break Glass with Guard – Charcoal
The Jack Fuse EBGC electronic break glass unit provides emergency door release with automatic, remote and local reset capability. Designed to suit access control, electric locks and automated entry systems, it eliminates the need for manual glass replacement while providing clear audible and visual activation feedback.
Key Features
- Automatic, remote and local reset options.
- Lift-up activation guard to reduce accidental operation.
- Audible activation sounder with adjustable volume.
- Back-lit status indication.
- Case and wall tamper switch.
- Local override switch for service or maintenance.
- Dual 3 amp relay contacts.
- Standard break glass mounting footprint for easy retrofit.
Specifications
- Item Code: EBGC
- Brand: Jack Fuse
- Product Type: Electronic break glass with guard
- Finish: Charcoal with Green Fascia
- Working Voltage: 12 or 24 volts direct current
- Relay Outputs: Two relays, 3 amp contacts
- Indicator: Back-lit LED status
- Sounder: Integrated activation sounder
- Reset Modes: Automatic, manual and remote
- Poles: Single pole switching
What's In The Box
- Electronic break glass unit with guard
- Mounting hardware
- Installation documentation
Suitable Uses
- Emergency door release for access-controlled doors.
- Electric locks, automatic doors and gate systems.
- New installations and retrofit applications.
- Remote or unattended facilities.
- Commercial and high-security sites.
Dimensions
Download PDF Resources
|
EBG V1 Datasheet |
|
Installation Note |
|
Quick Installation Guide |
Frequently Asked Questions
- Does this unit require glass replacement after activation?
No. It is an electronic break glass unit that resets automatically, remotely or locally without replacing any glass. - Can multiple units be reset from one control point?
Yes. Remote reset voltage can be shared across multiple units for centralised control. - What systems is this typically used with?
It is commonly used with access control electric locks, automatic doors and gate systems.
Additional Information
- Electronic reset capability reduces maintenance visits compared to traditional break glass units.
- Commonly specified on access-controlled egress doors in Australian commercial buildings.
- Guarded design helps reduce nuisance activations in public or high-traffic areas.
Technical Drawing
