HID ProxPoint Plus Mini Mullion Reader Classic – Charcoal Grey
The HID ProxPoint Plus mini mullion reader is a compact 125kHz proximity reader designed for door frame and mullion mounting where space is limited. It uses Wiegand output and pigtail wiring for straightforward integration with access control panels that accept Wiegand reader inputs.
Key Features
- 125kHz proximity mini mullion reader format.
- Wiegand output for controller integration.
- Pigtail wiring connection.
- Compact housing for narrow door frames and mullions.
- Low current draw for multi-reader installations.
Specifications
- Item Code: 6005BGB00
- Reader Type: ProxPoint Plus mini mullion reader
- Operating Frequency: 125kHz
- Output: Wiegand
- Wiring: Pigtail connection
- Input Voltage: 5V DC to 16V DC
- Current Draw: 35mA
- Finish: Charcoal Grey
What's In The Box
- 1 × HID ProxPoint Plus mini mullion reader
Suitable Uses
- Access controlled doors with narrow frames or mullion mounting points.
- Commercial sites using Wiegand based access control panels.
- Retrofit reader replacements where space is limited.
- Installations requiring low current draw per reader.
Dimensions
Frequently Asked Questions
- Is this reader suitable for narrow aluminium door frames?
Yes. It is a mini mullion format intended for tight mounting locations such as aluminium frames and mullions. - What voltage does it require?
It accepts 5V DC to 16V DC input, which suits many common access control power supplies and panels. - Does it connect using Wiegand?
Yes. It outputs Wiegand and uses a pigtail wiring connection.
Additional Information
- Mini mullion readers are commonly selected when the reader needs to be mounted on a slim jamb without projecting into the door swing path.
- When replacing an older reader, confirm the existing panel supports 125kHz proximity credentials and Wiegand wiring.
- Keep cable joins protected from moisture, particularly where the reader is fitted to external door frames.
