HID MaxiProx Long Range Reader – Charcoal Grey
The HID MaxiProx long range reader is designed for parking control and long read range access control applications. It combines the reader electronics in a single rugged housing intended for straightforward installation at vehicle entry and parking lanes.
It supports HID proximity credentials and is specified for applications where longer read distance is required compared with standard proximity readers.
Key Features
- Designed for parking control and long read range applications.
- Long read range up to 1.8m when used with ProxPass credentials.
- Autotune feature to help maintain read range near metal surfaces.
- Output options include Wiegand, Clock-and-Data and selectable serial outputs.
- Parking hold feature supports connection to a loop detector to improve vehicle detection accuracy.
- Compatible with HID cards and tags with formats up to 85 bits.
- Multicolour LED with internal or host control of LED and beeper.
- Two units can be installed approximately 1m apart for HI-LO vehicle lane setups.
- Reader supervision signal for CASI-RUSCO panels.
Specifications
- Item Code: 5375AGN00
- Reader Type: MaxiProx long range proximity reader
- Typical Read Range: Up to 1.8m (with ProxPass)
- Output: Wiegand (other outputs available in the range)
- Interface: RS-485
- Ingress Protection: IP55
- Finish: Charcoal Grey
What's In The Box
- 1 × HID MaxiProx long range reader
Suitable Uses
- Parking boom gates and vehicle entry control points.
- Long range credential reading using HID proximity credentials.
- Sites using loop detectors to manage parking lane access.
- Installations where the reader must be mounted near metal surfaces.
Dimensions
Frequently Asked Questions
- What read range can I expect?
It is specified for long range reading up to 1.8m when used with ProxPass credentials. Actual range depends on credential type and installation conditions. - Can it be installed close to metal posts or frames?
It includes an autotune feature intended to help maintain read range when installed near metal. Site conditions still affect performance. - Does it support loop detectors for parking lanes?
Yes. It includes a parking hold feature that allows connection to a loop detector to improve accurate vehicle detection in parking lanes.
Additional Information
- Long range readers are often used at vehicle entry points to reduce stop time and improve traffic flow compared with presenting a card at a short range reader.
- Where two vehicle types are present (for example cars and trucks), HI-LO layouts can use two readers at different heights to improve consistent credential reads.
- If you are integrating to panels that require supervised inputs, confirm the supervision method and wiring requirements for the specific controller brand.
