HID iCLASS SE Series RKLB40 Biometric Wall Plate Keypad Reader – Black
The HID iCLASS SE RKLB40 is a wall plate reader designed for multi factor access control applications, combining biometric fingerprint verification, keypad entry and contactless credential support in a single device.
Part of the iCLASS SE platform, the RKLB40 supports a wide range of credential technologies and form factors, including iCLASS Seos, iCLASS SE, iCLASS, MIFARE Classic and MIFARE DESFire EV1 cards and fobs, as well as mobile credentials using NFC and Bluetooth.
Key Features
- Biometric fingerprint reader with keypad and card technology.
- Supports iCLASS Seos, iCLASS SE and iCLASS credentials.
- Compatible with MIFARE Classic and MIFARE DESFire EV1.
- Supports mobile credentials via NFC and Bluetooth.
- 3 x 4 push button keypad for PIN entry.
- Secure Identity Object (SIO) platform.
- OSDP support for secure reader to controller communications.
- IP55 rated enclosure.
Specifications
- Item Code: 928NFNTEK000TE
- Reader Series: iCLASS SE Series
- Authentication Methods: Biometric, PIN and card or fob
- Keypad Layout: 3 x 4
- Credential Support: iCLASS Seos, iCLASS SE, iCLASS, MIFARE Classic, MIFARE DESFire EV1
- Mobile Credential Support: NFC and Bluetooth
- Output: Wiegand
- Communication: OSDP
- Working Voltage: 12V DC
- Ingress Protection: IP55
- Finish: Black
What's In The Box
- 1 × HID iCLASS SE RKLB40 biometric keypad reader
Suitable Uses
- High security commercial and government access control points.
- Doors requiring multi factor authentication.
- Sites transitioning to mobile credentials.
- Installations requiring biometric verification.
Dimensions
HID iCLASS Credential & Reader Range – Item Code Family
Frequently Asked Questions
- What authentication methods does this reader support?
It supports biometric fingerprint verification, PIN entry and contactless credentials. - Does it support mobile phone credentials?
Yes. It supports mobile credentials using NFC and Bluetooth where enabled in the system. - What is OSDP used for?
OSDP provides secure, supervised communication between the reader and the access control panel.
Additional Information
- Multi factor readers are commonly specified for higher security areas such as server rooms, restricted offices or critical infrastructure.
- OSDP is often preferred over Wiegand in new installations due to its encrypted and supervised communication.
- Biometric readers should be installed in accordance with site security and privacy policies.
