FSH Maglock Adjustable L Bracket to Suit FEM4300(M)
The FSH adjustable L bracket is a purpose-designed mounting accessory for FSH FEM4300 series electromagnetic locks. It is used where door frame depth or header width does not allow direct mounting of the maglock, most commonly on narrow header installations.
This bracket provides correct positioning and alignment of the magnetic lock body relative to the door leaf and armature plate, ensuring full holding force is achieved when installed correctly.
Key Features
- Adjustable L-shaped mounting bracket for electromagnetic locks.
- Designed specifically for FSH FEM4300 and FEM4300M series maglocks.
- Ideal for narrow header and restricted frame installations.
- Allows correct maglock alignment to achieve full holding force.
- Compatible with inward or outward opening door configurations when paired with correct armature mounting.
Specifications
Available Colour Variants
-
Satin Chrome
-
Black
Item Code Family
Warranty
Covered by the FSH 5 Year Mechanical and Electronic Warranty when installed and used in accordance with FSH and Allegion guidelines.
Frequently Asked Questions
When is an adjustable L bracket required?
An adjustable L bracket is required when the door frame header is too narrow to mount the maglock directly.
How many brackets are required for double doors?
Two brackets are required – one for each magnetic lock.
Is this bracket suitable for both monitored and non-monitored maglocks?
Yes. It suits both FEM4300 and FEM4300M models.
Additional Information
- Correct bracket selection is critical to achieve full maglock holding force.
- Armature plates must remain free-floating during installation.
- Always follow FSH mounting diagrams for inward and outward opening doors.
