FSH FES15 Rim Mount Electric Strike
The FSH FES15 is a rim-mounted electric strike designed for use with rim latches and surface-mounted deadlatches. It provides a simple and robust solution for access-controlled doors where a mortice strike is not suitable. The FES15 series supports field-selectable fail safe or fail secure operation and is compatible with a wide range of access control systems.
Key Features
- Surface-mounted electric strike for rim and surface deadlatch applications.
- Dual voltage operation: 12 VDC or 24 VDC.
- Field selectable Power To Lock (PTL) or Power To Open (PTO).
- Continuously rated solenoid suitable for constant duty.
- High holding strength exceeding 1250 kg.
- Non-monitored model rated to IP56 for weather resistance.
- Monitored version available with door status sensing.
Fire Rated
- Fire tested on door assemblies up to 4 hours.
- Tested in accordance with AS/NZS 1905.1 and BS 476 Part 22.
- Final fire door approval must be confirmed with the door manufacturer.
Specifications
.
Available Variants
Item Code Family
Warranty
Covered by the FSH 5 Year Mechanical and Electronic Warranty when installed and used in accordance with FSH and Allegion guidelines.
Frequently Asked Questions
Is the FES15 suitable for surface mounted rim locks?
Yes. The FES15 is specifically designed for rim and surface latch applications.
Does the FES15 support fail safe and fail secure?
Yes. The locking function is field selectable by reversing the barbell mechanism.
Is the monitored version weather resistant?
No. IP56 rating applies to the non-monitored FES15 only.
Additional Information
- Ensure a 1 mm latch clearance to prevent side loading on the strike keeper.
- Do not rotate the keeper while changing PTL/PTO mode to avoid damage to the barbell mechanism.
- Voltage selection must be set prior to applying power.
