FSH FES112 High Security Custodial Electric Strike – 2 Hour Fire Rated
The FSH FES112 is a high security custodial electric strike designed for heavy duty installations requiring extremely high holding strength. It is commonly specified in detention centres, correctional facilities and other secure environments where a double throw deadlock is used.
With a holding force exceeding 1000kg, multi voltage capability and full monitoring of door and strike status, the FES112 is suited to both new installations and retrofit high security projects.
Key Features
- Ultra high holding strength exceeding 1000kg.
- Designed for use with heavy duty double throw deadlocks.
- Fail secure operation (power to open).
- Full monitoring of strike, lock bolt, door position and cover plate.
- Multi voltage operation from 12 to 30 volts direct current.
- Series 2 to Series 3 changeover monitoring configuration.
- Hardened tooling steel body rated to 60 Rockwell.
- Molybdenum coated hardened steel jaws.
- Stainless steel faceplate and keeper.
Fire Rated
- 2 hour fire rated electric strike.
- SCEC approved for high security installations.
Specifications
- Item Code: FES112
- Function: Power to open (fail secure)
- Holding Strength: Over 1000kg
- Operating Voltage: 12–30V direct current (multi voltage)
- Current Draw: 1.5A at 12VDC, 0.75A at 24VDC
- Monitoring: Strike jaws, lock bolt status, door position reed switch, anti tamper cover monitoring
- Temperature Range: -20°C to 60°C
- Deadbolt Dimensions: Fully extended 33–36mm; width 10–17mm; height 57–59mm
- Construction: Hardened tooling steel body, molybdenum coated steel jaws, stainless steel faceplate
- Hardness: 60 Rockwell
- Approvals: 2 hour fire rated, SCEC approved
What's In The Box
- 1 × FSH FES112 custodial electric strike
- Series 2 to Series 3 changeover switch configuration
- Mounting hardware
Suitable Uses
- Detention centres and correctional facilities.
- Government and defence sites requiring SCEC approved hardware.
- High security commercial or industrial doors using double throw deadlocks.
- Retrofit upgrades to existing custodial door assemblies.
Dimensions
Frequently Asked Questions
- Is this strike suitable for fire doors?
Yes. The FES112 is rated for up to 2 hours on approved fire door assemblies when installed in accordance with the relevant fire door test data. - What type of lock is it designed to work with?
It is designed specifically for heavy duty double throw deadlocks commonly used in custodial or high security applications. - Can it be set to fail safe?
No. The FES112 is a fail secure (power to open) device and is not field selectable to fail safe.
Additional Information
- Commonly specified in Australian correctional, defence and government facilities requiring SCEC endorsed hardware.
- Series 3 monitoring configuration prevents the strike from securing unless the door is fully closed and the lock tongue is correctly engaged.
- Not suitable for standard latch locks or light duty deadbolts due to the custodial design and deadlock geometry requirements.
