FSH FEM4300D 280kg Double Maglock - Non-Monitored - 2 Hour Fire Rated - Satin Chrome
Key Features
- Double door electromagnetic lock with holding force up to 280 kilograms per magnet.
- Non-monitored configuration for straightforward access control systems.
- Dual voltage operation, field selectable between 12 Volt Direct Current and 24 Volt Direct Current.
- Built-in metal oxide varistor surge protection.
- Designed with no residual magnetism to reduce door binding after release.
- Successfully fire tested up to 2 hours on compliant fire door assemblies.
- Supplied with a 5 year mechanical warranty.
Fire Rated
- Successfully tested up to 2 hours on fire door assemblies in accordance with AS 1905.1, Part 1, Fire Resistant Doorsets.
- Fire rating is dependent on the complete door set configuration and compliant installation.
Specifications
- Item Code: FEM4300D
- Brand: FSH
- Maglock Type: Double door electromagnetic lock
- Monitoring: Non-monitored
- Holding Strength: Up to 280 kilograms per magnet
- Working Voltage: 12 Volt or 24 Volt Direct Current (field selectable)
- Current Draw: 1 ampere at 12 Volt Direct Current, 500 milliampere at 24 Volt Direct Current
- Magnet Body Size: 477 millimetre length × 48 millimetre height × 25 millimetre depth
- Armature Plate Size: 185 millimetre length × 38 millimetre height × 12 millimetre depth (two plates)
- Finish: Satin Chrome
- Fire Rated: Yes, up to 2 hours
What's In The Box
- FSH FEM4300D double electromagnetic lock body
- Two armature plates
- Fixing hardware supplied with the maglock
Suitable Uses
- Commercial and industrial double door access control systems.
- Fire rated door assemblies requiring electromagnetic locking.
- Sites requiring fail-safe unlocking on power loss for emergency egress.
Dimensions
Frequently Asked Questions
- Is this maglock suitable for double fire doors?
Yes. This model has been successfully tested up to 2 hours on compliant fire door assemblies, subject to correct door set installation. - Does this model provide monitoring outputs?
No. This is a non-monitored double maglock and does not provide lock or door status signals. - What power supply does this maglock require?
It is field selectable for either 12 Volt or 24 Volt Direct Current. Current draw is 1 ampere at 12 Volt or 500 milliampere at 24 Volt.
Additional Information
- This double maglock is commonly used on commercial double leaf doors where equal holding force is required on both leaves.
- Correct armature alignment on both doors is essential to achieve full holding strength.
- Fire rated performance depends on the complete door set and approved installation method.
