Dormakaba Closer TS83 EN3-6 Backcheck Delayed Action Parallel Arm Bracket - Silver
Key Features
- Variable closing force EN3 to EN6 for a wide range of door sizes.
- Adjustable closing speed and latching speed via separate valves.
- Integrated backcheck to reduce door and frame impact.
- Adjustable delayed action for controlled closing in high traffic areas.
- Non-handed design suits left or right hand doors.
- Overhead surface mounted closer for commercial applications.
- Includes parallel arm bracket and flat-form arm assembly.
- Suitable for internal and external outward opening doors.
- Fire rated configuration.
Fire Rated
- Suitable for fire door assemblies when installed to the manufacturer’s instructions.
Specifications
- Item Code: DOTS8300SIL
- Model: TS83
- Closing Force: Adjustable EN3 to EN6
- Mounting: Overhead surface mounted
- Arm Type: Parallel arm bracket included
- Backcheck: Adjustable
- Delayed Action: Adjustable
- Hold Open: No
- Door Width: Up to 1400 mm (standard installation)
- Door Width (parallel arm): Up to 950 mm
- Dimensions: 245 mm length x 46 mm width x 60 mm height
- Weight: 1.7 kg
- Finish: Silver
- Handing: Non-handed
What's In The Box
- TS83 door closer body
- Flat-form arm assembly
- Parallel arm bracket
- Fixing screws and installation instructions
Suitable Uses
- Commercial internal and external hinged doors.
- Office, retail and industrial buildings.
- Fire door installations where a non hold open closer is required.
- Sites requiring adjustable closing force and delayed action.
Dimensions
Download PDF Resources
|
Dormakaba TS83 Door Closer Brochure |
Frequently Asked Questions
- Is this closer suitable for fire doors?
Yes, the TS83 is suitable for fire door assemblies when installed in accordance with the manufacturer’s fire test approvals and correct mounting configuration. - Does this model include hold open?
No. This configuration does not include a hold open function and is suitable for fire doors where hold open is not permitted. - When is delayed action typically used?
Delayed action is commonly used in hospitals, aged care, or public buildings where slower closing allows safe passage for people or trolleys.
Additional Information
- TS83 closers are commonly specified on Australian commercial doors due to their wide adjustment range and proven reliability.
- Parallel arm mounting is often used on push side installations to reduce projection into walkways and improve vandal resistance.
- Delayed action should be set carefully to avoid excessively slow closing that may affect fire door performance.
Technical Drawing
