Dorma Push Pull Plate Set 300 x 75 mm with D Handle – Satin Stainless Steel
Key Features
- Back-to-back push and pull plate set for through-door fixing.
- Exterior: plain push plate with concealed fixing.
- Interior: pull handle plate with visible fixing.
- 200 mm x 16 mm D handle on internal plate.
- Plates sized 300 mm x 75 mm x 2 mm with 10 mm radius corners.
- Fixing screws suit door thickness up to 60 mm.
- Stainless steel construction.
- Supplied as a complete set with fixing screws.
- Satin stainless steel finish.
Specifications
- Item Code: DO375SET2
- Product Type: Push pull plate set (back-to-back)
- Set Includes: 1 x push plate (concealed fix) and 1 x pull handle plate (visible fix)
- Plate Size: 300 mm (H) x 75 mm (W) x 2 mm (D)
- Corners: 10 mm radius
- D Handle Size: 200 mm (L) x 16 mm (Diameter)
- Door Thickness Suitability: Up to 60 mm
- Material: Stainless steel
- Fixing: Screw fix, through-door. Exterior concealed fix
- Sold As: Set
- Finish: Satin Stainless Steel
What's In The Box
- 1 × Plain push plate (concealed fix)
- 1 × Pull handle plate with 200 mm x 16 mm D handle (visible fix)
- Fixing screws for door thickness up to 60 mm
Suitable Uses
- Shopfront and commercial entry doors requiring push/pull operation.
- Internal access doors in offices, schools, and public buildings.
- Doors where back-to-back hardware is preferred for strength and clean appearance.
Dimensions
Frequently Asked Questions
- Is this supplied as a complete back-to-back set?
Yes. It is supplied as a push plate and a pull handle plate designed to fix back-to-back through the door. - What door thickness do the screws suit?
The supplied screws suit door thickness up to 60 mm. - What is the difference between concealed and visible fixing in this set?
The exterior push plate is concealed fix for a cleaner look, while the interior plate uses visible fixing around the handle plate.
Additional Information
- Push pull plate sets are commonly used on doors without latching hardware, such as reception, corridor, or shopfront swing doors.
- Through-door fixing typically provides better long-term strength than screw fixing into thin aluminium or hollow metal stiles.
- When retrofitting, check internal door clearances so the pull handle plate does not interfere with door closers or seals.
