Zanda PS.260.SSS – Heavy Duty Floor Mount Spindle for Pivot Doors – Satin Stainless Steel
The Zanda PS.260.SSS is a high-performance floor mount spindle designed for modern pivot door systems. Installed directly beneath the door leaf, it remains concealed while delivering exceptional load-bearing capacity and smooth operation. Constructed from 304-grade stainless steel, the PS.260 is engineered for free-swinging doors in both single and double configurations. With oil-impregnated bronze bearings and compatibility with PS.170 and PS.180 top pivots, it’s the ideal choice for premium architectural applications.
Key Features
- Free-swinging floor mount spindle design
- Fully concealed under the door leaf for clean aesthetic
- Bronze oil-impregnated bearings for low maintenance
- 304 grade stainless steel plate construction
- Allows doors to swing both ways
- FD30 and FD60 compliant to BS 476
- Compatible with PS.170 & PS.180 top pivots
- Ideal for modern architectural spaces
Specifications
- Item Code: PS.260.SSS
- Type: Floor Mount Spindle for Pivot Doors
- Spindle Bearing Size: 90mm x 50mm
- Door Thickness: 44mm and above
- Max Door Width: 1100mm
- Max Door Weight: 80kg
- Finish: Satin Stainless Steel
- Compatibility: PS.170, PS.180
- Warranty: 10-Year Mechanical Warranty
Available Finish Options
-
Satin Stainless Steel
Suitable Uses
- Contemporary architectural entrances
- Commercial and residential pivot doors
- Single and double door applications
- Fire-rated door systems (FD30 & FD60)
- Internal or external pivot systems
What's In The Box
- 1x PS.260 Floor Mount Spindle Bearing (90x50mm)
- Installation Screws
- Installation Instructions
