Datatek 6RU 450mm Deep Wall Mount Data Cabinet – FPS Series (Includes Accessories)
Key Features
- 6 rack unit wall mount cabinet for standard 19 inch rack equipment.
- FPS series supplied with cooling and power accessories pre-installed.
- Heavy duty cold rolled steel welded frame.
- Reinforced tempered glass front door with metal surround.
- Removable side panels with keyed locking.
- Supplied fully assembled for rapid installation.
Specifications
- Item Code: 24B6RW64FPS
- Rack Type: Wall mount
- Total Rack Units: 6RU
- Mounting Hole Type: Square
- Load Capacity: 40 kg
- Ingress Protection: IP20
- Material: Cold rolled steel cabinet with tempered glass door
- Finish: Black
What's In The Box
- 6RU wall mount data cabinet (assembled)
- Fixed internal shelf
- Cooling fan (pre-installed)
- 5 outlet power distribution unit
- 12 × M6 cage nut screws
- 4 × wall mounting bolts
- 2 × cabinet keys
Suitable Uses
- Office and retail network installations.
- Wall mounted racks requiring integrated power and airflow.
- Small server, switching and patch panel environments.
Dimensions
| Width | Depth | Height |
|---|---|---|
| 600 mm | 450 mm | 370 mm |
Datatek 6RU Wall Mount Cabinet – Item Code Family
| Item Code | Configuration | Description |
|---|---|---|
| 24B6RW64FPS | 450 mm Depth – FPS | Wall mount cabinet with cooling fan, fixed shelf and 5 outlet PDU |
| 24B6RW64 | 450 mm Depth | Standard wall mount cabinet without accessories |
| 24B6RW63 | 300 mm Depth | Shallow depth wall mount cabinet |
| 24B6RWS66 | 600 mm Depth – Swing Frame | Swing frame wall mount cabinet without accessories |
| 24B6RWS66FPS | 600 mm Depth – Swing Frame FPS | Swing frame cabinet with fans, shelf and power rail |
Download PDF Resources
Frequently Asked Questions
- What does the FPS series include?
The FPS configuration includes a cooling fan, fixed shelf and a 5 outlet power distribution unit. - Is the cabinet supplied assembled?
Yes. The cabinet is delivered fully assembled and ready for wall mounting. - Is active cooling required?
For higher heat loads, the FPS series is commonly specified to improve airflow inside the cabinet.
Additional Information
- FPS variants are commonly selected where equipment density or power draw is higher.
- Wall mounting must be into structural framing or masonry suitable for combined cabinet and equipment weight.
- For rear access without removal, swing frame variants may be preferred.
