Datatek 22RU 600mm Deep Floor Standing Data Cabinet – FPS Series
The Datatek 22RU 600mm Deep Floor Standing Data Cabinet from the FPS Series is designed for secure housing of network, server and communications equipment. It is commonly specified in server rooms, wiring closets, industrial facilities and commercial installations where equipment protection, airflow and service access are critical.
Key Features
- 22RU floor standing cabinet with 600mm internal depth.
- Tempered glass front door with metal frame.
- Removable side panels with keyed locks.
- Front and rear doors keyed alike.
- High load capacity steel construction.
- Supplied fully assembled.
Specifications
- Item Code: 24A22R66FPS
- Rack Type: Floor standing
- Total Rack Units: 22RU
- Mounting Hole Type: Square
- Load Capacity: 800 kg
- Rack IP Rating: IP20
- Material: Cold rolled steel with tempered glass door
- Colour: Black
- Standards: ANSI/EIA RS-310-D, IEC297-2, DIN41491, ETSI (manufacturer stated)
What's In The Box
- 4 × ceiling mounted cooling fans
- 1 × 6 outlet power distribution unit
- 2 × fixed shelves
- 1 × set of cabinet keys
- Adjustable levelling feet
- Castors
- Removable cable entry cover plates
Suitable Uses
- Server rooms and data centres.
- Commercial and industrial network installations.
- Audio visual and control system racks.
Dimensions
Download PDF Resources
Frequently Asked Questions
- Is this cabinet supplied assembled?
Yes. The cabinet is supplied fully assembled from the factory. - Does this cabinet include cooling fans?
Yes. Four ceiling mounted fans are included as standard. - Can the cabinet be moved after installation?
Yes. Castors are supplied for positioning, with levelling feet for final placement.
Additional Information
- FPS Series cabinets are commonly specified where bundled accessories reduce installation time.
- Square mounting rails allow use of standard cage nuts and bolts.
- Side panels can be removed for easier equipment installation and servicing.
Technical Drawing
