Datatek 12RU 600mm Swing Frame Wall Mount Data Cabinet – 600W x 600D x 635H mm
The Datatek 12RU 600mm swing frame wall mount data cabinet is designed to improve access during installation and servicing by allowing the cabinet to swing out from the wall. This model includes practical accessories for small network builds, including a fixed shelf, ceiling mounted fans, and a 6-way power rail.
Key Features
- 12RU swing frame cabinet design for rear access without full removal.
- 600 mm cabinet depth for deeper networking equipment.
- Toughened glass front door with metal frame.
- Over 180 degree door opening.
- Lockable doors and removable side panels.
- Vented top and bottom for airflow.
- Supplied fully assembled.
Specifications
- Item Code: 24B12RWS66FPS
- Rack Type: Wall mounted swing frame
- Total Rack Units: 12RU
- Equipment Mounting Holes: Square
- Load Capacity: 60 kg
- Rack IP Rating: IP20
- Materials: Cold rolled steel with tempered glass door
- Colour: Black
What's In The Box
- 1 × Datatek 12RU swing frame wall mount data cabinet (assembled)
- 1 × fixed shelf
- 2 × ceiling mounted fans
- 1 × 6-way power rail (power distribution unit)
- 12 × M6 cage nut screws
- 4 × mounting bolts
- 2 × keys
Suitable Uses
- Network installations where rear access is required for patching and servicing.
- Office and commercial comms cupboards with limited working space.
- Sites using deeper rack equipment that benefits from 600 mm cabinet depth.
Dimensions
| Measurement | Value |
|---|---|
| Width | 600 mm |
| Depth | 600 mm |
| Height | 635 mm |
Datatek Data Cabinet and Accessories – Item Code Family
| Item Code | Configuration | Rack Units | Depth | Notes |
|---|---|---|---|---|
| 24B12RW64 | Wall Mount | 12RU | 450 mm | Standard wall mount cabinet |
| 24B12RWS66FPS | Swing Frame Wall Mount | 12RU | 600 mm | This product |
| 24B18RW64FPS | Wall Mount | 18RU | 450 mm | Includes fans, power rail, shelf |
| 24B18RWS66FPS | Swing Frame Wall Mount | 18RU | 600 mm | Includes fans, power rail, shelf |
| 24A18R66FPS | Floor Standing | 18RU | 600 mm | Floor cabinet with inclusions |
| 24D1UCS30 | Cantilever Shelf | 1RU | 300 mm | Suits 450 mm deep cabinets |
Download PDF Resources
Frequently Asked Questions
- What does the swing frame design help with?
It allows the cabinet to swing out from the wall, improving access to the rear of rack-mounted equipment. - Are the included fans and power rail pre-fitted?
Included accessories are listed for this model; confirm final installation state during commissioning. - What load capacity is supported?
This cabinet is rated to a maximum load capacity of 60 kg.
Additional Information
- Swing frame cabinets are commonly chosen when rear cable management access is required after installation.
- Confirm wall structure suitability for the combined cabinet and equipment load before mounting.
- Fan operation and airflow should be checked during commissioning to suit your equipment heat load.
