Dahua WizSense TIOC Duo Series 2x4MP Dual-Lens Eyeball Network Camera with 2.8mm Fixed Lens – IP67 – White
The Dahua WizSense TIOC Duo dual-lens eyeball network camera delivers a seamless 180 degree panoramic view using two 4 megapixel sensors. It combines active deterrence, smart analytics and dual illumination in a compact IP67 rated housing, making it suitable for both indoor and outdoor surveillance.
Key Features
- Dual 4MP sensors producing an 8MP panoramic image.
- 180 degree wide angle splicing view.
- 2.8mm fixed focal dual lens design.
- Smart dual illumination with IR and warm light.
- Active deterrence with red and blue warning lights.
- EPTZ intelligent target tracking.
- Built in microphone and speaker with two way audio.
- Alarm input and output.
- MicroSD card support up to 256GB.
- 12V DC or PoE power supply.
- IP67 weather resistant housing.
Specifications
- Item Code: PDW3849A180ASPV
- Brand: Dahua
- Series: WizSense TIOC Duo
- Camera Type: Dual lens eyeball network camera
- Resolution: 2 × 4MP (8MP combined)
- Lens: Dual 2.8mm fixed lenses
- Viewing Angle: 180 degree panoramic
- Compression: H.265, H.264
- Illumination: IR up to 25m, warm light up to 20m
- Audio: Built in microphone and speaker
- Storage: MicroSD up to 256GB
- Power: 12V DC or PoE
- Ingress Protection: IP67
- Colour: White
What's In The Box
- Dahua dual lens eyeball network camera
- Mounting hardware
- Installation guide
Suitable Uses
- Perimeter monitoring and wide area surveillance.
- Commercial and industrial sites.
- Car parks, entrances and outdoor areas.
- Retail and public spaces requiring panoramic coverage.
Dimensions
| Dimension | Size |
|---|---|
| Height | 135.2 mm |
| Diameter | 122 mm |
Frequently Asked Questions
- Does this camera provide a full 180 degree view?
Yes. The dual lens design stitches the image together to create a seamless 180 degree panoramic view. - Can it be used outdoors?
Yes. The IP67 rating provides protection against dust and water for outdoor installations. - Does it support audio recording?
Yes. It includes a built in microphone and speaker for two way audio.
Additional Information
- Dual lens design reduces blind spots compared to single lens cameras.
- Active deterrence helps prevent incidents before they occur.
- PoE support simplifies installation by using a single cable for power and data.
Technical Drawing
