Dahua WizSense Series 8MP Eyeball Network Camera with 2.7–13.5mm Varifocal Lens – IP67 – White
Key Features
- 8 megapixel network camera delivering up to 3840 × 2160 resolution at 25 or 30 frames per second.
- 2.7 to 13.5 millimetre motorised varifocal lens for flexible field of view adjustment.
- WizSense artificial intelligence with human and vehicle classification for intrusion and tripwire events.
- AI Scene Self-Adaption technology for automatic image optimisation in changing environments.
- Smart Codec technology supporting Smart H.264 Plus and Smart H.265 Plus to reduce storage usage.
- Built-in infrared illumination with up to 40 metre night vision range.
- Integrated microphone for audio recording where permitted.
- IP67-rated housing suitable for outdoor installation.
Specifications
- Item Code: HDW3866TPZS
- Camera Type: Internet Protocol eyeball network camera
- Image Sensor: 1/2.8 inch Complementary Metal Oxide Semiconductor
- Maximum Resolution: 3840 × 2160
- Lens: 2.7–13.5 millimetre motorised varifocal
- Infrared Distance: Up to 40 metres
- Video Compression: H.264, H.264 Plus, H.265, H.265 Plus
- Storage: Micro Secure Digital card slot supporting up to 256 gigabytes
- Audio: Built-in microphone
- Power Supply: 12 Volt Direct Current and Power over Ethernet
- Ingress Protection: IP67
- Finish: White
What's In The Box
- Dahua WizSense HDW3866TPZS eyeball network camera
- Mounting screws and fixing hardware
- Quick start guide
Suitable Uses
- Commercial building surveillance including offices and retail spaces.
- Industrial sites requiring perimeter protection and analytics.
- Outdoor installations where weather resistance is required.
- Applications needing adjustable focal length without lens replacement.
Dimensions
| Measurement | Value |
|---|---|
| Height | 108.3 millimetres |
| Base Diameter | 122 millimetres |
Download PDF Resources
Frequently Asked Questions
- Is this camera suitable for outdoor installation?
This camera carries an IP67 rating, making it suitable for exposed outdoor environments. - Does this camera support human and vehicle detection?
Yes, WizSense analytics enable accurate classification of humans and vehicles for supported detection rules. - Can the lens be adjusted after installation?
The motorised varifocal lens allows remote adjustment through the camera interface.
Additional Information
- This model is commonly specified in Australian commercial and industrial surveillance projects.
- Correct camera height and angle are critical to achieve reliable human and vehicle classification.
- Micro Secure Digital card recording should be considered supplementary to a network video recorder.
Technical Drawing
