Dahua WizSense Series 6MP TIOC 3.0 Active Deterrence Eyeball Network Camera with 2.8mm Fixed Lens – AcuPick Technology – IP67 – Black
Key Features
- 6 megapixel eyeball network camera delivering high-resolution video.
- TIOC 3.0 active deterrence with red and blue warning lights and audible alarm.
- AcuPick technology for rapid human and vehicle target search.
- Smart Dual Illumination combining infrared and warm light.
- SMD 4.0 with accurate human and vehicle classification.
- Fixed 2.8 mm lens providing wide-angle surveillance coverage.
- Two-way audio with dual microphones and integrated speaker.
- IP67 rated for reliable outdoor installation.
Specifications
- Item Code: DHIPCHDW3649HASPVANZS2B
- Camera Resolution: 6 Megapixels
- Image Sensor: 1/2.7 inch Complementary Metal Oxide Semiconductor
- Maximum Resolution: 3200 × 1800
- Lens Type: Fixed focal
- Lens Size: 2.8 mm
- Video Compression: H.265, H.264
- Illumination: Infrared and warm light up to 30 metres
- Audio: Dual microphones and integrated speaker, two-way audio
- Alarm Input and Output: 1 in, 1 out
- Storage: Micro Secure Digital card support up to 256 gigabytes
- Ingress Protection: IP67
- Power Supply: 12 Volt Direct Current and Power over Ethernet
- Finish: Black
What's In The Box
- Dahua 6 megapixel TIOC 3.0 eyeball network camera
- Mounting hardware
- Quick start guide
Suitable Uses
- Commercial and industrial security surveillance
- Retail, offices and building entrances
- Sites requiring visible active deterrence
Dimensions
| Measurement | Value |
|---|---|
| Diameter | 122.0 mm |
| Height | 110.9 mm |
Item Code Family
| Item Code | Camera Type | Notes |
|---|---|---|
| DHIPCHDW3649HASPVANZS2B | Eyeball | This product |
PDF Resources
Frequently Asked Questions
- Is this camera suitable for outdoor installation?
Yes. The camera is rated IP67 for protection against dust and water ingress. - Does this model provide active deterrence?
Yes. It includes warning lights and a built-in speaker for visual and audible deterrence. - Can the camera record audio?
Yes. Dual microphones and a speaker support two-way audio communication.
Additional Information
- Active deterrence features can be scheduled or triggered by analytics events.
- AcuPick significantly reduces time spent searching recorded footage.
- Commonly specified in Australian commercial and retail surveillance projects.
Technical Drawing
