Dahua Wizmind Series 8MP Eyeball Network Camera with 2.8mm Fixed Lens – AcuPick – IP67 – White
Key Features
- 8 megapixel 1/1.8 inch CMOS image sensor delivering high resolution video
- Fixed 2.8 mm lens suitable for wide area monitoring
- AcuPick technology for fast and accurate target search
- Built in infrared illumination with up to 50 m night vision range
- Advanced artificial intelligence analytics including people counting and video metadata
- Supports Smart H.264 and Smart H.265 video compression
- Integrated microphone for audio recording
- IP67 rated housing for outdoor environments
Specifications
- Item Code: HDW5842TMPASES3
- Resolution: 8 megapixels
- Lens: 2.8 mm fixed focal
- Image Sensor: 1/1.8 inch CMOS
- Infrared Distance: Up to 50 m
- Compression: H.264, H.265, Smart H.264+, Smart H.265+
- Audio: Built in microphone
- Storage: Supports Micro SD card up to 512 GB
- Power Supply: 12 V DC or Power over Ethernet
- Ingress Protection: IP67
What's In The Box
- Dahua 8MP eyeball network camera
- Mounting hardware
- Quick start guide
Suitable Uses
- Commercial and industrial security surveillance
- Retail analytics and people counting applications
- Outdoor perimeter monitoring
- Car parks and building entrances
Dimensions
| Measurement | Size (mm) |
|---|---|
| Overall height | 99.1 |
| Base diameter | 121.9 |
| Inner mounting diameter | 84.0 |
| Mounting hole size | 4.5 × 5.5 |
Item Code Family
| Item Code | Camera Type | Description |
|---|---|---|
| HDW5842TMPASES3 | Eyeball Network Camera | This product – 8MP fixed lens eyeball camera with AcuPick |
| DHSD8C848PA1HNF | PTZ Network Camera | 8MP PTZ camera with 48x optical zoom and auto tracking |
PDF Resources
Frequently Asked Questions
- Is this camera suitable for outdoor installation?
Yes, it is IP67 rated and designed for outdoor commercial environments. - Does this camera support Power over Ethernet?
Yes, it supports PoE as well as 12 volt DC power input. - Can this camera record audio?
Yes, it includes a built in microphone for audio capture.
Additional Information
- AcuPick technology is designed to reduce time spent searching footage by isolating human and vehicle targets.
- Commonly specified in Australian commercial security installations.
- Correct mounting orientation is essential for optimal AI analytics performance.
Technical Drawing
