Dahua WizColor Series 5MP Eyeball Network Camera with 2.8mm Fixed Lens - IP67 - White
The Dahua DHIPCHDW2549EMPSPROANZ is a 5 megapixel IP eyeball network camera from the WizColor series, designed to deliver full-colour video in low-light environments. Using a 1/1.8 inch CMOS image sensor, AI-powered analytics and built-in warm illumination, it is commonly specified for Australian commercial and industrial surveillance installations.
Key Features
- 5 megapixel resolution using a 1/1.8 inch CMOS image sensor
- 2.8 mm fixed focal lens for wide-angle coverage
- Built-in warm light for colour imaging in low-light scenes
- AI ISP with WizColor technology for enhanced night performance
- SMD Plus for accurate human and vehicle classification
- Perimeter protection with intrusion and tripwire analytics
- Built-in microphone for audio recording
- Supports MicroSD cards up to 256 GB
- Power over Ethernet or 12 V Direct Current supply
- IP67 rated housing for outdoor installation
Specifications
- Item Code: DHIPCHDW2549EMPSPROANZ
- Camera Resolution: 5 Megapixels
- Image Sensor: 1/1.8 inch CMOS
- Lens: 2.8 mm fixed focal
- Illumination: Built-in warm light
- Video Compression: H.265 and Smart H.265+
- Audio: Built-in microphone
- Storage: MicroSD card support up to 256 GB
- Power Supply: 12 V Direct Current and Power over Ethernet
- Ingress Protection: IP67
- Finish: White
Available Finish Options
- White – DHIPCHDW2549EMPSPROANZ
- Black – HDW2549EMPSPROANZBLK
What's In The Box
- 5MP eyeball network camera
- Mounting screws and anchors
- Quick start guide
Suitable Uses
- Commercial offices and buildings
- Industrial sites and warehouses
- Retail stores and shopping centres
- Outdoor perimeter surveillance
Dimensions
| Diameter | 106.0 mm |
| Height | 96.6 mm |
Item Code Family
Download PDF Resources
Frequently Asked Questions
- Is this camera suitable for outdoor installation?
Yes. The IP67 rated enclosure allows installation in exposed outdoor environments. - Does this camera support Power over Ethernet?
Yes. It supports both Power over Ethernet and 12 V Direct Current power input. - Does this camera provide colour images at night?
Yes. Built-in warm illumination and WizColor technology enable colour night imaging.
Additional Information
- Detection accuracy depends on mounting height and camera angle.
- Warm light may attract insects when installed outdoors.
- Commonly installed using junction boxes or pole mounts.
Technical Drawing
.
