Dahua VTO2000a Series Reader Module Stainless Steel
The Dahua VTO2000AR is a MiFare card reader module designed for the Dahua VTO2000a modular outdoor intercom system. It provides card based access control functionality and must be used in conjunction with a compatible VTO2000a control module.
Key Features
- MiFare card reader module for Dahua VTO2000a systems.
- Stainless steel front panel for outdoor use.
- Modular design supporting large multi module intercom assemblies.
- Designed for surface mounted or flush mounted installations.
- Rated to IP54 with IK07 impact resistance.
Specifications
- Item Code: VTO2000AR
- Product Type: Card reader module
- Card Technology: MiFare
- Material: Stainless steel
- Finish: Stainless Steel
- Ingress Protection: IP54
- Impact Rating: IK07
- Mounting: Surface mount or flush mount
What's In The Box
- VTO2000a series reader module
Suitable Uses
- Card based access control for Dahua modular intercom systems.
- Apartment, commercial and multi tenant entry installations.
- Outdoor intercom stations requiring MiFare credential support.
VTO2000a Series Modular Components – Item Code Family
Frequently Asked Questions
- Can this reader operate on its own?
No. It must be connected to a Dahua VTO2000a control module to function. - What card type does this reader support?
It supports MiFare card credentials only. - Is this suitable for outdoor installation?
Yes. The module is rated to IP54 with IK07 impact resistance.
Additional Information
- This module is commonly combined with camera, button and control modules to build custom entry stations.
- Maximum supported module count depends on the control module used.
- Correct module alignment is important when assembling multi module panels.
