Dahua Lite Series 5MP Eyeball HDCVI Camera with 2.8mm Fixed Lens - Starlight Technology and Power Over Coax - IP67 - White
The Dahua HACHDW1500TMQPA0280BS2 is a 5 megapixel HDCVI eyeball camera designed for high definition analogue CCTV systems. It features Starlight low light performance, a 2.8mm fixed focal lens, Smart Infrared up to 60 metres, and a built in microphone for audio recording on supported recorders.
Key Features
- Up to 25 frames per second at 5 megapixel resolution in 16:9 format.
- Switchable video output modes including HDCVI, Composite Video, Analogue High Definition and Television Interface.
- Quick to install eyeball housing for faster setup.
- 2.8mm fixed focal lens for wide angle coverage.
- Built in microphone for audio capture.
- Smart Infrared with up to 60m night vision range.
- IP67 rated housing suitable for outdoor installations.
- 12V DC power input with Power Over Coax support on compatible recorders.
Specifications
- Item Code: HACHDW1500TMQPA0280BS2
- Manufacturer Model: DH-HAC-HDW1500TMQP-A-0280B-S2
- Camera Type: Eyeball
- Camera Resolution: 5 Megapixel
- Lens: 2.8mm fixed focal
- Infrared Range: Up to 60m
- Audio: Built in microphone
- Ingress Protection: IP67
- Power: 12V DC
- Finish: White
Dimensions
| Diameter | Height |
| 109.9 mm | 100.9 mm |
Item Code Family
| Item Code | Technology | Lens | Finish | Notes |
|---|---|---|---|---|
| HACHDW1500TMQPA0280BS2 | HDCVI | 2.8mm fixed | White | This product |
| HDW2541EMPASANZBLK | IP Network | 2.8mm fixed | Black | Network camera variant |
| DHIPCHDW2541EMPASANZ | IP Network | 2.8mm fixed | White | Network camera variant |
What's In The Box
- 1 x Dahua 5MP HDCVI eyeball camera with 2.8mm lens
Download PDF Resources
Technical Drawing
.
