Dahua Lift Control Module - Lift Controller (VTM416)
The Dahua DHVTM416 lift controller is designed for managing lift floor permissions within Dahua IP intercom and access control systems. It integrates with door stations, indoor monitors and readers to control floor access via network-based authorisation.
Key Features
- Supports connection of 1 Wiegand reader and 2 RS485 readers.
- Cascading support for up to 8 controllers, allowing up to 128 floors permission control.
- Six alarm inputs and two alarm outputs.
- Stores up to 30,000 alarm and log records.
- Supports up to 60 call lift modules.
- All floor permissions are released when the fire alarm input is triggered.
- Remote configuration and control via web client.
Specifications
- Item Code: DHVTM416
- Manufacturer Model: VTM416
- Communication: TCP/IP, RS485, Wiegand
- Relay Outputs: 16
- Alarm Inputs: 6
- Alarm Outputs: 2
- Power Supply: 12V DC 2A or via VTNS1060A
- Operating Temperature: -20 degrees Celsius to 55 degrees Celsius
- Humidity: 10 to 90 percent relative humidity
- Weight: 1.0 kg
Dimensions
| Length | Height | Depth |
| 210 mm | 116 mm | 29 mm |
What's In The Box
- 1 x Dahua VTM416 lift controller module
Download PDF Resources
Frequently Asked Questions
- How many floors can this controller manage?
Up to 128 floors when cascading up to 8 lift controllers. - Does it support fire alarm integration?
Yes. When the fire alarm input is triggered, all floor permissions are released. - Can this be configured remotely?
Yes. Configuration and control are available through the web client.
Additional Information
- Typically installed within lift control cabinets or secure service risers.
- RS485 port allocation should be planned carefully when cascading controllers.
- Fire alarm behaviour must be tested and commissioned to local compliance requirements.
Technical Drawing
