Dahua IP Intercom 6 Port PoE Switch – VTNS1060AA – White
The Dahua VTNS1060AA is a dedicated network power supply switch designed for Dahua IP intercom systems. It delivers both power and data over Cat 5e cabling and supports up to six indoor monitors. A 24 volt DC power supply is included.
Key Features
- Dahua protocol network power supply switch
- Supports up to 6 Dahua IP indoor monitors
- Power and data transmitted over a single Cat 5e cable
- Six Power over Ethernet ports
- DIN rail mountable design
- 24 volt DC power supply included
Specifications
- Item Code: VTNS1060AA
- Finish: White
- Working Voltage: 24 volt DC
- Ethernet Interface: RJ45
- PoE Ports: 6
- Total Ports: 8
- DIN Rail Mountable: Yes
Electrical Performance
- Standby power consumption: 0.2 W (no load)
- Maximum power consumption: 45 W (full load)
- Operating temperature range: -10 °C to 55 °C
Suitable Uses
- Dahua IP residential intercom systems
- Apartment and unit block video intercom installations
- Multi dwelling developments using Dahua indoor monitors
What’s In The Box
- Dahua VTNS1060AA 6 port PoE switch
- 24 volt DC power supply
- Mounting accessories
- Quick start documentation
Dimensions
| Length | Width | Depth |
|---|---|---|
| 178.8 mm | 107.1 mm | 30.3 mm |
Frequently Asked Questions
- Is the power supply included?
Yes. A 24 volt DC power supply is supplied with this unit. - How many indoor monitors can be connected?
Up to six Dahua IP indoor monitors can be connected. - Does this switch provide Power over Ethernet?
Yes. Six PoE ports are provided.
Additional Information
- Purpose built for Dahua IP intercom ecosystems
- Commonly installed in communication or structured wiring cabinets
- DIN rail mounting simplifies professional installation
