Dahua Access ANPR 4MP Bullet Network Camera with 2.7–12 mm Varifocal Lens
The Dahua DHIITC413PW4DIZ1 is a dedicated Access Automatic Number Plate Recognition (ANPR) bullet camera designed for vehicle access control and traffic monitoring. It combines a 4 megapixel image sensor with embedded deep learning analytics to deliver reliable plate capture and vehicle metadata extraction in demanding outdoor environments.
Key Features
- 4 megapixel Access ANPR network camera.
- Motorised 2.7–12 mm vari focal lens.
- Maximum vehicle detection speed up to 80 km/h.
- Deep learning algorithms for plate, vehicle brand and colour recognition.
- Integrated interfaces for barriers, gates and access controllers.
- Built in LED for simplified installation and commissioning.
- All in one housing with integrated junction box and mounting bracket.
- IP67 weather resistance and IK10 impact protection.
Specifications
- Item Code: DHIITC413PW4DIZ1
- Product Series: Dahua Access ANPR
- Camera Resolution: 4 megapixels
- Lens Type: Motorised vari focal
- Focal Length: 2.7–12 mm
- Maximum Detection Speed: 80 km/h
- Camera Housing: IP bullet
- Ingress Protection: IP67
- Impact Rating: IK10
- Finish: Silver and Black
Dimensions
| Overall Length | 395.0 mm |
| Body Height | 127.8 mm |
| Front Width | 60.6 mm |
| Mount Diameter | 70.0 mm |
Item Code Family
| Item Code | Lens | Detection Speed |
|---|---|---|
| DHIITC413PW4DIZ1 | 2.7–12 mm motorised vari focal | Up to 80 km/h |
| DHIITC413PW4DIZ3 | 8–32 mm motorised vari focal | Up to 120 km/h |
Download PDF Resources
Frequently Asked Questions
- Is this camera designed specifically for ANPR?
Yes. It is purpose built for automatic number plate recognition. - Can this camera integrate with barriers or gates?
Yes. It supports integration with external access control equipment. - Is this suitable for outdoor installation?
Yes. Rated IP67 and IK10 for harsh outdoor environments.
Additional Information
- Correct mounting height and lens selection are critical for accurate number plate capture.
- Commonly specified in Australian commercial and industrial access control projects.
