Dahua Access Anpr 4mp Bullet Network Camera with 2.7-12mm Varifocal Lens - IP67 and IK10 - Silver & Black

Dahua Access ANPR 4MP Bullet Network Camera with 2.7–12 mm Varifocal Lens

The Dahua DHIITC413PW4DIZ1 is a dedicated Access Automatic Number Plate Recognition (ANPR) bullet camera designed for vehicle access control and traffic monitoring. It combines a 4 megapixel image sensor with embedded deep learning analytics to deliver reliable plate capture and vehicle metadata extraction in demanding outdoor environments.

Key Features

• 4 megapixel Access ANPR network camera.
• Motorised 2.7–12 mm vari focal lens.
• Maximum vehicle detection speed up to 80 km/h.
• Deep learning algorithms for plate, vehicle brand and colour recognition.
• Integrated interfaces for barriers, gates and access controllers.
• Built in LED for simplified installation and commissioning.
• All in one housing with integrated junction box and mounting bracket.
• IP67 weather resistance and IK10 impact protection.

Specifications

• Item Code: DHIITC413PW4DIZ1
• Product Series: Dahua Access ANPR
• Camera Resolution: 4 megapixels
• Lens Type: Motorised vari focal
• Focal Length: 2.7–12 mm
• Maximum Detection Speed: 80 km/h
• Camera Housing: IP bullet
• Ingress Protection: IP67
• Impact Rating: IK10
• Finish: Silver and Black

Dimensions

Item Code Family

Download PDF Resources

• Dahua ITC413-PW4D Series Datasheet

Frequently Asked Questions

• Is this camera designed specifically for ANPR?
  Yes. It is purpose built for automatic number plate recognition.
• Can this camera integrate with barriers or gates?
  Yes. It supports integration with external access control equipment.
• Is this suitable for outdoor installation?
  Yes. Rated IP67 and IK10 for harsh outdoor environments.

Additional Information

• Correct mounting height and lens selection are critical for accurate number plate capture.
• Commonly specified in Australian commercial and industrial access control projects.
