Dahua 20 Port Layer 2 Cloud Managed Network Switch with 16 PoE Ports
The Dahua DHCS422016GT190 is a Layer 2 cloud managed network switch designed for small to medium surveillance and network deployments. It provides 16 Power over Ethernet ports for powering network devices, alongside dedicated uplink and SFP ports for flexible network expansion.
Key Features
- Layer 2 cloud managed desktop network switch.
- Sixteen Power over Ethernet ports for connected devices.
- Supports intelligent PoE power management.
- Dedicated Gigabit uplink and SFP ports for network expansion.
- Full metal enclosed housing for durability and heat dissipation.
Specifications
- Item Code: DHCS422016GT190
- Model Reference: CS4220-16GT-190
- Switch Type: Layer 2 managed
- Total Ports: 20
- PoE Ports: 16
- Uplink Ports: 2 × Gigabit Ethernet
- SFP Ports: 2
- PoE Standards: IEEE 802.3af, IEEE 802.3at, Hi-PoE, IEEE 802.3bt
- Network Standards: IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x
- Management: Cloud managed
- Finish: Black
What's In The Box
- Dahua CS4220-16GT-190 network switch.
- Power supply.
- Quick start documentation.
Suitable Uses
- Internet Protocol surveillance camera installations.
- Small to medium commercial networks.
- Systems requiring centralised PoE power management.
Download PDF Resources
Frequently Asked Questions
- Can this switch power IP cameras directly?
Yes. Sixteen ports support Power over Ethernet for compatible devices. - Is this switch cloud managed?
Yes. The switch supports Dahua cloud-based management features. - Does it support fibre uplinks?
Yes. Two SFP ports are provided for fibre connections.
Additional Information
- Intelligent PoE allows remote control of power delivery to individual ports.
- Commonly specified in Australian CCTV and access control networks.
- Metal enclosure assists with heat dissipation in continuous operation environments.
.
