Dahua 10 Port Layer 2 Cloud Managed Network Switch with 8 PoE Ports Plus 2 Uplink Ports
The Dahua DHCS40108ET110 is a compact Layer 2 cloud managed network switch designed for reliable PoE device connectivity. It features eight PoE Ethernet ports and two uplink ports, supporting intelligent PoE power management within a durable metal enclosure.
Key Features
- 10 port network switch with 8 PoE Ethernet ports.
- Layer 2 cloud managed functionality.
- Supports IEEE802.3, IEEE802.3u and IEEE802.3ab standards.
- Compatible with IEEE802.3af, IEEE802.3at, Hi-PoE and IEEE802.3bt.
- Intelligent PoE power management.
- Fully enclosed metal housing with dust resistant design.
Specifications
Dimensions
| Overall Width | 158.0 mm |
| Overall Height | 132.9 mm |
| Mounting Height | 130.0 mm |
| Overall Depth | 35.1 mm |
| Internal Depth | 25.0 mm |
Additional Information
- This switch is commonly used in IP CCTV, access control and network infrastructure installations.
- Cloud management allows remote monitoring and configuration via supported Dahua platforms.
- PoE power budgeting and device prioritisation should be configured during commissioning.
