CS EVO2/4 Controller Mounting Plate 250 x 170 x 1.2mm – Black
The CS4765 is a wall-mount controller mounting plate designed to suit CS Technologies EVO2 and EVO4 controller boards. It provides a neat mounting surface for installing EVO controllers on a wall or panel.
Key Features
- Mounting plate designed to suit CS Technologies EVO2 and EVO4 controller boards.
- Supports wall mounting of controllers for tidy cabinet or panel layouts.
- Australian made and designed.
Specifications
- Item Code: CS4765
- Product Type: Controller mounting plate
- Suits: CSEVO boards (EVO2 and EVO4)
- Finish: Black
- Plate Thickness: 1.2 mm
- Country of Manufacture: Australia
Dimensions
| Measurement | Size |
|---|---|
| Overall Length | 250 mm |
| Width | 170 mm |
| Thickness | 1.2 mm |
Suitable Uses
- Mounting EVO2 and EVO4 controller boards inside access control cabinets.
- Wall mounting controllers where a separate enclosure or panel is being built.
- Neat retrofit mounting where the controller needs a stable back plate.
Frequently Asked Questions
- Does this plate include plastic standoffs for mounting the controller board?
No. The plastic standoffs shown are for illustration only. Standoffs are included with EVO2 and EVO4 boards. - Is this plate only for EVO2, or can it be used for EVO4 as well?
It suits both EVO2 and EVO4 controller boards. - Can this be used for cabinet builds and wall mounting?
Yes. It is intended to support wall mounting and tidy controller placement within panels or enclosures.
Additional Information
- This mounting plate is typically used to keep EVO controllers square and supported when installed in metal cabinets or custom panels.
- If you are planning cable management, allow room around the board edges for reader, power, and input wiring terminations.
- Because standoffs are supplied with EVO2 and EVO4 boards, installers commonly keep spare standoffs on hand for service replacements.
