Creone Valuebox System 7005S Backup Battery Audit Trail - White
The Creone Valuebox System 7005S is a five compartment valuables cabinet from the System series, combining a keypad with an integrated display for overview and configuration. It provides audit trail visibility directly on the display and supports optional administration via the KeyWin Light PC program (ordered separately), allowing event logging and system management across multiple connected cabinets.
Key Features
- System series keypad with integrated display for programming and monitoring.
- Five individually controlled compartments.
- Supports up to 500 user codes (1 to 8 characters).
- Stores up to 3,600 events.
- Audit trail viewable on the display.
- Validity settings per code including date range and number of uses.
- One code can be assigned to one or multiple compartments.
- Includes date and time display with time zone support.
- Expandable with up to 15 expansion cabinets.
- Connection support for external alarm and external card reader.
- Mains powered with backup battery.
Specifications
- Item Code: CR1413481
- Series: Valuebox System
- How Many Compartments: 5
- Key Capacity: 5
- Amount of User Codes: 500
- Event Storage: Up to 3,600 events
- Audit Trail: Yes
- USB-A Interface: Yes (INTRFACE1)
- Battery Backup: Yes
- Capacity Expandable: Yes (up to 15 expansion cabinets)
- Working Voltage: 240 Volt alternating current
- Material: Steel (1.5 mm)
- Finish: White
- Weight: 20 kg
Dimensions
| External (Width × Height × Depth) | 745 × 460 × 284 mm |
What's In The Box
- Creone Valuebox System 7005S cabinet
- Five compartment doors
- Integrated keypad and display
- Backup battery
Suitable Uses
- Secure storage of valuables requiring on-site audit visibility.
- Facilities managing multiple users with compartment-level access control.
- Sites planning scalable valuables management systems.
Item Code Family – Creone Valuebox System 7000S Series
Download PDF Resources
Frequently Asked Questions
- Does this model provide an audit trail?
Yes. Events are logged and can be viewed directly on the cabinet display. - Can this cabinet be managed from a computer?
Yes. Administration can be performed using the KeyWin Light PC program, which is ordered separately. - What is a common installation consideration?
Ensure the cabinet date and time are correctly set before relying on event timestamps.
Additional Information
- System series cabinets are commonly specified where on-site audit visibility is required without permanent network connectivity.
- Expansion cabinets share the same keypad and logic as the main cabinet.
- Careful planning of compartment numbering helps simplify administration as systems grow.
