Creone Valuebox System 7002S Backup Battery Audit Trail 2 Door Unit - White
The Creone Valuebox System 7002S is a two compartment valuables cabinet in the System series, combining a keypad with a display for on-site overview and straightforward programming. Events can be viewed on the display as an audit trail, and the system supports optional PC administration using KeyWin Light (ordered separately) to log and save events. The System series supports mixed expansion, allowing up to 15 expansion cabinets to be added to the same keypad managed system.
Key Features
- System series keypad with display for overview, menus, and programming.
- Stores up to 500 user codes (1 to 8 characters).
- Stores up to 3,600 events.
- Audit trail and event log viewable in the display.
- Validity settings per code, including time period and number of uses.
- One code can be assigned to one or more compartments.
- Built in date and time display, including time zones.
- Options including double code, block function, and service menu.
- Expandable with up to 15 cabinets from the Expansion series.
- Can connect to external alarm and external card reader.
- Simple power connection (mains power) and backup battery.
Specifications
- Item Code: CR1413451
- Series: Valuebox System
- How Many Compartments: 2
- Key Capacity: 2
- Amount of User Codes: 500
- Event Storage: Up to 3,600 events
- Audit Trail: Yes
- Battery Backup: Yes
- USB-A Interface: Yes (INTRFACE1)
- Capacity Expandable: Yes (up to 15 expansion cabinets)
- Working Voltage: 240 Volt alternating current
- Material: Steel (1.5 mm)
- Finish: White
- Weight: 20 kg
Dimensions
| External (Width × Height × Depth) | 745 × 460 × 284 mm |
What's In The Box
- Creone Valuebox System 7002S cabinet with display and keypad
- Two compartment doors
- Backup battery
Suitable Uses
- Controlled storage of small valuables where audit trail visibility is required on site.
- Facilities needing user code management with expiry or limited-use settings.
- Sites planning a multi-cabinet system managed from a single keypad.
Item Code Family – Creone Valuebox System 7000S Cabinets
Download PDF Resources
Frequently Asked Questions
- Does this model keep a record of events?
Yes. It stores events and shows the event log and audit trail in the display, with capacity for up to 3,600 events. - Can I manage the system from a computer?
Yes. It can be administered using the KeyWin Light personal computer program, which is ordered separately. - What is a common configuration mistake to avoid?
Not setting the correct date and time before relying on the audit trail, as timestamps are based on the cabinet clock.
Additional Information
- In practice, audit trail on the display is most useful for quick checks, while KeyWin Light is typically used when you need longer-term storage of logs.
- If integrating an external card reader or alarm input, confirm the site wiring plan before mounting the cabinet due to cable entry and service access.
- Where multiple cabinets are planned, map compartment numbering early so user permissions remain easy to administer as expansion cabinets are added.
