Creone Keybox 9002E Expansion Cabinet with 16 Key Hook Capacity - 2 Door Unit - White
The Creone Keybox 9002E is an expansion cabinet designed to increase key storage capacity when connected to a Creone Basic or System main key cabinet. It adds two additional controlled doors with a total of 16 key hook positions while maintaining consistent cabinet colour, size, and installation appearance.
Key Features
- Expansion cabinet providing 16 key hook positions across two doors.
- Designed to be combined with Creone Basic or System main key cabinets.
- Doors are managed and controlled by the keypad on the main key cabinet.
- Expandable using up to 15 expansion cabinets from a single main cabinet.
- Steel cabinet construction with powder coated white finish.
Specifications
- Item Code: CR141312
- Product Type: Expansion key cabinet
- Key Capacity: 16 keys
- Doors: 2 doors (8 key hooks per door)
- Material: Steel
- Finish: White
- Working Voltage: Not applicable
- Audit Trail: No
- Amount of User Codes: 0
- Battery Backup: No
- Capacity Expandable: Yes
- Expandable Limit: Up to 15 expansion cabinets (via a main cabinet)
- Weight: 4.3 kg
Dimensions
| Height | 345 mm |
| Width | 280 mm |
| Depth | 94 mm |
What's In The Box
- Creone Keybox 9002E expansion cabinet (2 door unit)
- Pre-fitted key hooks (16 total)
Suitable Uses
- Sites using Creone Basic or System key cabinets that need extra key hook capacity.
- Facilities where key storage needs to expand over time without changing the main cabinet.
- Commercial, industrial, and institutional key management installations.
Item Code Family - Creone Keybox Cabinets (As Provided)
Frequently Asked Questions
- Can this expansion cabinet operate on its own?
No. This model requires a Creone Basic or System main key cabinet to manage and control the doors. - How many expansion cabinets can be added to a main cabinet?
A main key cabinet in the Creone Basic or System range can be expanded using up to 15 expansion cabinets. - What is a common installation mistake to avoid?
Mixing cabinet types. This expansion cabinet is controlled by a Creone main cabinet, while no PCB cabinets are intended for third party access control systems.
Additional Information
- This expansion cabinet is intended to match the cabinet size and finish of compatible Creone main cabinets for consistent wall-mounted installations.
- All access permissions and door control functions are handled by the connected main cabinet, not by this expansion cabinet.
- If a project requires solenoid driven doors controlled by a third party access control system, a no PCB cabinet model is typically used instead of a Creone expansion cabinet.
