Dormakaba Furniture Coastal Round Rose Pair with 70 Levers (Levers Only) - Satin Stainless Steel
The Dormakaba Coastal 4000 series round rose lever set pairs a concealed-fix round rose with 70 series levers for residential and commercial doors. This set is manufactured from solid 316 grade stainless steel and is supplied as a complete back-to-back lever pair with spindles and fixings. The lever profile is confirmed as AS1428.1 compliant and the set has been successfully tested up to 4 hours on fire door assemblies (depending on doorset type) to AS 1905.1-2005 Part 1.
Key Features
- Coastal 4000 series round rose lever furniture with concealed fittings.
- Supplied with 70 series levers (levers only configuration).
- Hygienic, corrosion resistant 316 grade stainless steel construction.
- Designed to fit back to back as a lever set.
- Bolt through fixing for secure mounting.
- AS1428.1 compliant disabled access lever profile.
- Successfully tested up to 4 hours on fire door assemblies (doorset dependent) to AS 1905.1-2005 Part 1.
- Finished in Satin Stainless Steel.
Specifications
- Item Code: DK430070SSS
- Series: Coastal 4000
- Furniture Type: Round rose lever set (concealed fix)
- Lever Series: 70 levers (levers only)
- Material: Solid stainless steel
- Grade of Stainless Steel: 316
- Rose Size: 53 mm (diameter) × 10 mm (projection)
- Horizontal Fixing Centres: 41 mm
- Fixing Method: Bolt through fixing
- Door Thickness Suitability: 32 mm to 50 mm
- Suits Lock Series: Dormakaba DKMS2602SSS series mortice locks
- AS1428.1 Compliant Lever: Yes
- Fire Rated: Yes, tested up to 4 hours (doorset dependent) to AS 1905.1-2005 Part 1
- Finish: Satin Stainless Steel
- Sold As a Set: Yes
What's In The Box
- 2 × 70 series levers (back-to-back set)
- 2 × concealed fix round roses
- Split spindle and solid spindle
- Fixing screws
Suitable Uses
- Commercial and residential hinged doors requiring a round rose lever set.
- Projects requiring an AS1428.1 compliant lever profile.
- Coastal or high humidity environments where 316 stainless steel is specified.
- Doors using compatible Dormakaba mortice locks (including DKMS2602SSS series).
Dimensions
Frequently Asked Questions
- Does this include the mortice lock or cylinder?
No. This is the lever and rose set only. The compatible mortice lock and cylinder are selected separately. - Is this lever compliant for disability access projects?
Yes, the lever set is confirmed as BCA AS1428.1 -2009 compliant. - Can this be installed on fire doors?
The leverset has been successfully tested up to 4 hours on fire door assemblies (doorset dependent) to AS 1905.1-2005 Part 1. Always confirm the complete doorset approval for your specific fire door configuration.
Additional Information
- 316 stainless steel levers are commonly specified in Australian coastal builds, aged care, and public amenities due to hygiene and corrosion resistance requirements.
- Back-to-back fixing is typical for commercial doors to improve rigidity and reduce the risk of loosening over time.
- When pairing with cylinders, confirm the correct cylinder length for 32-50 mm doors and any door skins or escutcheon thickness.
