Chubb Mortice Lock CH3C10SC73 - Satin Chrome
The Chubb/Union 3C10 is a heavy duty mortice deadlock designed to accept a euro profile cylinder (cylinder not included). It uses two independently operated internal levers within the case to control deadlocking of the bolt, a design intended to help frustrate manipulation attempts. This model is commonly specified on hinged timber doors where a robust deadlocking function is required.
Key Features
- Heavy duty mortice deadlock case.
- Suits euro style cylinders (not included).
- Two independently operated internal levers control deadlocking of the bolt.
- Independent lever design intended to frustrate manipulation attempts.
- Bolt through fixing for secure installation.
- Satin Chrome finish.
Specifications
- Item Code: CH3C10SC73
- Lock Type: Mortice deadlock
- Uses Cylinder Type: Euro fixed cam
- Backset: 44 mm
- Case Depth: 73 mm
- Case Height: 122 mm
- Face Plate Size: 178 mm (L) x 25 mm (W)
- Suits Door Thickness: No less than 40 mm
- Fixing: Bolt through fixing
- Finish: Satin Chrome
Dimensions
| Backset | 44 mm |
| Case Depth | 73 mm |
| Case Height | 122 mm |
| Face Plate Length | 178 mm |
| Face Plate Width | 25 mm |
What's In The Box
- 1 × Chubb/Union 3C10 mortice deadlock body
- Face plate (as supplied on the lock case)
Suitable Uses
- Hinged timber doors requiring a heavy duty mortice deadlock.
- Doors where euro profile cylinder keying is required (cylinder supplied separately).
- Commercial and residential projects using euro profile locking systems.
Chubb Mortice Lock 73 mm Case Depth – Item Code Family
Frequently Asked Questions
- Does this mortice lock include a euro cylinder?
No. It suits euro profile cylinders, but the cylinder is not included with the lock body. - What door thickness does this suit?
The product information states it suits hinged wooden doors not less than 40 mm thick. - What is a common installation detail to check?
Confirm the backset and case depth match the door preparation before fitting the lock body.
Additional Information
- Euro profile mortice deadlocks are commonly specified where keying is managed via interchangeable euro cylinders.
- Independent internal lever designs are typically chosen in higher risk applications where manipulation resistance is desired.
- When retrofitting, confirm the door edge preparation suits a 73 mm case depth and 44 mm backset before ordering.
