Brava Metro EA Series Glass Door Knob Set – 70 mm Backset – Antique Copper
The Brava Metro EA Series Glass Door Knob Set is a commercial grade cylindrical knobset designed for glass door applications. It features keyed operation from both sides and forms part of the Brava Metro EA3000 spherical knob range.
Fire Rated
Successfully tested up to 4 hours (depending on type of doorset) on fire door assemblies in accordance with Australian Standard AS 1905.1-2005, Part 1: Fire Resistant Doorsets.
Key Features
- Glass door function with keyed operation from both sides.
- Outside and inside keys lock and unlock both knobs.
- Cylindrical fixing with Silca LW5 profile 6 pin cylinder.
- Incorporates the PD 8221 barrel.
- Compatible with most restricted keying systems.
- Supplied boxed and colour coded with 2 keys.
Specifications
- Item Code: EA3711AC70
- Function: Glass Door
- Backset: 70 mm
- Door Thickness: 35 mm to 45 mm
- Cylinder: LW5 profile
- Rose Diameter: 75 mm
- Finish: Antique Copper
- Lock Grade: Commercial
- Lock Type: Cylindrical
What's In The Box
- 2 × spherical knobs
- 70 mm backset latch
- LW5 profile cylinder
- Strike and fixings
- 2 keys
Suitable Uses
- Commercial glass doors.
- Internal fire-rated door assemblies where approved.
- Sites requiring keyed access from both sides.
Dimensions
| Rose Diameter | 75 mm |
| Maximum Projection | 69.5 mm |
| Door Thickness | 35 mm to 45 mm |
| Knob Diameter | 54 mm |
Brava Metro EA Series – Item Code Family
Download PDF Resources
Frequently Asked Questions
- Is this knob set suitable for fire doors?
Yes, when installed as part of an approved fire-rated doorset. - Can this be keyed alike?
It is compatible with most restricted keying systems using LW5 profile cylinders. - Is this suitable for timber doors?
This model is designed for glass door applications only.
Additional Information
- Glass door knobsets require correct glass preparation before installation.
- Fire rating applies only when installed as part of a compliant doorset.
- Confirm keying requirements prior to ordering.
